5 Day/night 1135
6 Outdoor 1136
7 Tamper 1137
8 Near alarm 1138
EXAMPLE
Assuming for a given installation it is required to differentiate between entry/exit, interior and general
burglary zones, and assuming that zone 1 is a front door (Entry/Exit zone), zone 2 is an interior PIR
(Interior zone) and zone 3 is a general burglary zone.
Program the following locations
1. Location 86 (Zone 1) = 4 (Code 1134 = ENTRY/EXIT)
2. Location 88 (Zone 2) = 2 (Code 1132 = INTERIOR)
3. Location 90 (Zone 3) = 10 (Code 1130 = BURGLARY)
NOTES ON DOMESTIC REPORTING:
If dual reporting is enabled then domestic reporting will dial both phone numbers as programmed into
locations 48-63 and 64-79. The data to be reported will be transmitted 3 times immediately after the
phone number is dialled. This format provides for a simple form of easily identifiable remote alarm which
may be reported to an office, mobile phone etc.
When using Domestic Reporting the number will be dialled and the data will be transmitted the number of
times as programmed into the number of dial attempts (location 151).
NOTES ON PROGRAMMING TELEPHONE NUMBERS:
To dial a "0" program a [10] into the location.
To dial a "*" program an [11] into the location.
To dial a "#" program a [12] into the location.
To create a 12 second pause in the number program a [14] into the location.
To create a 4 second pause in the number program a [15] into the location.
To terminate a telephone number, program a [0] (not 10) into the location immediately following
the last digit of the telephone number.
LOCATIONS 48-63 Primary Telephone Number
Loc. No. 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63
