IDS 805 Installer Manual 700-266-02H Issued September 2009
For the correct operation of this switch, refer to Section 8: Hardware Reset Switch.
LOCATIONS 22-41 Programmable Output Controls
SEE: LOCATIONS 158 - 170 for Additional Programmable Outputs
These locations control the functioning of the 5 onboard programmable outputs. If a smoke detector,
strobe light (or any other device requiring power) is connected to a programmable output, a relay board
must be used to provide the high current. Please refer to the Section 5. Programmable Outputs.
Multiple events may be programmed to a single output. The output may be programmed to function as
follows:
 Output pulsed for two seconds.
 Output may be latched high.
 Output may be latched low.
Table 6: Output Options
Programmable Output
Program Value
Pulsed
Set Port High
Set Port Low
Output 1
1
6
11
Output 2 2 7 12
Output 3 3 8 13
Output 4
4
9
14
Output 5 5 10 15
 The strobe and fire-detect outputs may only be programmed with [0] to [5] i.e. a pulsed output.
 The second phone number dialled output can only be programmed with values [1] - [5] ([0] will
disable the output).
