22 Alarm 2 Pulse prog. O/P 2
23 Audible priority 1 Pulse prog. O/P 1
24 Low battery 0 Disabled
25 Auto test 0 Disabled
26 Duress 1 Pulse prog. O/P 1
27 AC fail 0 Disabled
28 Close 8 Set prog. O/P 3 High
29 Open 13 Set prog. O/P 3 Low
30 AC restore 0 Disabled
31 Cancel 0 Disabled
32 Fire 0 Disabled
33 Medical 0 Disabled
34 Strobe 0 Disabled
35 Tamper 0 Disabled
36 Silent priority 1 Pulse prog. O/P 1
37 Fire detector power 0 Disabled
38 Chime 0 Disabled
39 Communication fail 0 Disabled
40 Phone No. 2 dialled 0 Disabled
41 D/L complete 0 Disabled
Programming Example
Program output No. 2 to report open and close, with close HIGH and open LOW:
It will be noted from Table 7 that output No. 2 is already assigned as the alarm output. This condition first
needs to be disabled from output 2 before a new condition may be assigned otherwise CLOSE, OPEN
and ALARM will all be programmed to Programmable Output 2. To do this a [0]
should be programmed
into location 22.
The location for a close instruction is location 28. From Table 6 it will be noted that a value of [7]
programmed into this location will cause output 2 to go high. This output will remain high until the
appropriately programmed value gives the instruction for this output to be set low. It will be noted that
location 29 corresponds to an open condition. From Table 6 it will be noted that a value of [12]
will drive
output 2 low. Therefore, if a value of [12]
is programmed into location 29 output 2 will be set low on an
open condition.
If an output is programmed as a strobe output, the output will follow the sequence illustrated below.
