Appendix A - Installation and Test Operator Information
Installation
1. Unpacking and Inspection
Your tester was shipped in a custom foam insulated container that complies with ASTM D4169-92a Assurance Level II
Distribution Cycle 13 Performance Test Sequence.
If the shipping carton is damaged, inspect the contents for visible damage such as dents, scratches, or broken meters. If the
tester is damaged, notify the carrier and the Slaughter Company customer support department immediately. Please save
the shipping carton and packing material for the carrier’s inspection. Our customer support department will assist you in
the repair or replacement of your tester. Please do not return your product without rst notifying us and receiving an RMA
(return materials authorization) number.
2. Safe Lifting and Carrying Instructions
Proper methods of lifting and carrying can help to protect against injury. Follow the recommendations below to ensure that
testers are handled in a safe manner.
• Determine if the tester can be lifted by one individual or requires additional support.
• Make sure that your balance is centered and your feet are properly spaced, shoulder width apart behind the tester.
• Bend at the knees and make sure your back is straight.
• Grip the tester with your ngers and palms, and do not lift unless your back is straight.
• Lift up with your legs, not your back.
• Keep the tester close to your body while carrying.
• Lower the tester by bending your knees. Keep your back straight.
3. Contents of the Carton
Inside the carton will be the following:
DESCRIPTION SLA PART NUMBER
290 Series Tester 290 Series Hipot and IR Tester
High Voltage Lead 102-055-913
Cable Assembly Return Lead (2 Qty) 102-069-904
Fuse (2 Qty) Fuse 3.15A 250V Fast-Blow 20mm
Interlock Connector 99-10040-01
USB Cable 99-10797-01
USB Flash Drive (Product Manual) 99-10726-01
Line Cord* 125-013-001
High Voltage Probe** 102-050-913
Fuse 15A 250V Slow-Blow 30mm** 99-10020-01
Line Cord for 298** 99-10164-01
*The Line Cord listed is American. Other combinations of the Line Cord are available upon request.
** Only applicable for Model 298
WARNING
ONLY ACCESSORIES WHICH MEET THE MANUFACTURER’S SPECIFICATION SHALL BE USED.
