Appendix E - Replacement Parts List - Model 290
Part Number QTY Reference
Designator
Description
Supplied Accessories
99-10020-01 2 Fuse 3.15A 250V Fast-Blow 20mm
99-10040-01 1 Interlock Connector
102-069-904 2 Cable Assembly Return Lead
102-055-913 1 High Voltage Lead
125-013-001 1 Cable Input Cordset USA
99-10164-01* 1 Cable Input Cordset USA
99-10797-01 1 USB Cable
99-10726-01 1 USB Flash Drive (Product Manual)
99-10656-01* 2 Fuse 15A 250V Slow-Blow 30mm
102-050-913* 1 High Voltage Probe
Panel Components
99-10297-01 1 Fuse Holder 20mm
99-10727-01 1 High Voltage Connector
99-10017-01 2 Return Connector
99 -10312-01 1 Power Switch 2P/15A
99-10016-01 1 Earth Connector
99-10735-01 1 Rotary Knob
330 -113-001 1 TEST Test Switch Green Lighted
330 -113-002 1 RESET Reset Switch Red Lighted
99-10763-01 1 Feet Kit w/o Rubber Inserts
175-974 -002 2 Rubber Insert for Front Feet
99-10762-01 2 Rubber Insert for Rear Feet
99-10736-01 1 16x2 OLED LCD
175-936 -002 1 Case Handle
99-10650-01* 1 Fuse Holder 30mm
99-10850-01* 1 16x2 OLED LCD
PCB Assemblies
99-10745-01 1 AMGSP7100 Amplier Board
99-10746-01 1 CNTSG7100 Continuity Board
99-10747-01 1 CONSG7100 Main Control Board
99-10748-01 1 EVRSG7100 Encoder Board
99-10749-01 1 HRYSG7100 High Voltage Relay Board
99-10750-01 1 LEDM001B LED Assembly
Internal Components
99-10751-01 1 T2 High Voltage Output Transformer
*Only applicable for Model 298
To Next Page
