User Manual 5-2 V2.0
Application Kit TC3X7 ADAS V2.0 2018-06
Application Kit Manual TC3X7 ADAS
Hardware: Application Kit TC3X7 ADAS V2.0
Signal (on board used) Description
5.4 Clock Signals
5.5 Debug Signals
5.6 Peripheral Signals
Table 5-4 Clock Signals
Short name Description
XTAL1 Crystal Oscillator Input
XTAL2 Crystal Oscillator Output
Table 5-5 Debug Signals
Short name Description
/TRST Test Reset
DAP0 Device Access Port Line 0 / Test Data Clock (TCK)
DAP1 Device Access Port Line 1 / Test Data Select (TMS)
P21.6 Test Data Input (TDI)
P21.7 DAP2 / TDO from debug connectors
Table 5-6 Peripheral Signals
Short name Description
P14.1 ASCLIN0 Receive Input A
P14.0 ASCLIN0 Transmit Output
P10.6 ASCLIN2 Receive Input D
P10.5 ASCLIN2 Transmit Output
P15.4 I2C0 Serial Clock
P15.5 I2C0 Serial Data Input C und Output
P33.7 RTC Alarm Interrupt Input
P20.7 CAN00 Receive Input B (optional)
P20.8 CAN00 Transmit Output (optional)
P10.2 CAN02 Receive Input E
P10.3 CAN02 Transmit Output
P11.0 Ethernet TXD3 Output
P11.1 Ethernet TXD2 Output
P11.2 Ethernet TXD1 Output
P11.3 Ethernet TXD0 Output
P11.4 Ethernet TXCLK Output
P11.5 Ethernet GREFCLK Input
P11.6 Ethernet TCTL Output
P11.7 Ethernet RXD3 Input A
P11.8 Ethernet RXD2 Input A
