40 InFocus Corporation — Introduction Guide - DLP Multimedia Projector
Bottom
P130, P131, P132 6 & 9 input/output models
Name Function
1 Mounting points for optional ceiling mount Attach the optional ceiling mount when suspending the projector
from a ceiling (three points)
2 Adjustable front foot Used to level the projector or move the height of the image
3 Rear Feet (2) Used to level the projector in combination with the front foot
4 Security cable attachment point Pass a commercially available cable lock through here to secure the
projector.
You can also attach the optional commercially available wire through
here to prevent the projector from falling when ceiling or wall
mounted
Parts and functions
