Ingersoll-Rand Thermo King V-520 MAX 30 User Manual

41
Specifications
Electrical System
Fuses
12 Volt 24 Volt
Fuse 1: Power Supply Circuit 5 amps 5 amps
Fuse 2: Condenser Fan Motor (CFM1) 15 amps 10 amps
Fuse 3: Evaporator Fan Motor (EF1) 15 amps 10 amps
Fuse 4: Evaporator Fan Motor (EF2) 15 amps 10 amps
Fuse 5: Compressor Clutch 1 (CCL1), Liquid Injection Switch (LIS),
Liquid Injection Valve(LIV), Host Defrost Hot Solenoid Valve (PS1),
Compressor otor Contactor (CMC), Heat Pilot Solenoid (PS5),
Compressor Clutch 2 (CCL2)
20 amps 10 amps
Fuse 6: Condenser Fan 1, 2 (CF1, CF2) Heater 1, Heater 2 (HT1,
HT2)
10 amps 7.5 amps
Fuse 7: Condenser Fan Motor (CFM2) 15 amps 10 amps
Fuse 8: Remote Liquid Solenoid Valve (PS2), Host Liquid Solenoid
Valve (PS3), Remote Defrost Hot Gas Solenoid Valve (PS4)
20 amps 10 amps
Fuse 9: Evaporator Fan Motor (EF3) 15 amps 10 amps
Fuse 10: Evaporator Fan Motor (EF4) 15 amps 10 amps
Fuse 11: Heaters 10 amps 7.5 amps
41
Specifications
Electrical System
Fuses
12 Volt 24 Volt
Fuse 1: Power Supply Circuit 5 amps 5 amps
Fuse 2: Condenser Fan Motor (CFM1) 15 amps 10 amps
Fuse 3: Evaporator Fan Motor (EF1) 15 amps 10 amps
Fuse 4: Evaporator Fan Motor (EF2) 15 amps 10 amps
Fuse 5: Compressor Clutch 1 (CCL1), Liquid Injection Switch (LIS),
Liquid Injection Valve(LIV), Host Defrost Hot Solenoid Valve (PS1),
Compressor otor Contactor (CMC), Heat Pilot Solenoid (PS5),
Compressor Clutch 2 (CCL2)
20 amps 10 amps
Fuse 6: Condenser Fan 1, 2 (CF1, CF2) Heater 1, Heater 2 (HT1,
HT2)
10 amps 7.5 amps
Fuse 7: Condenser Fan Motor (CFM2) 15 amps 10 amps
Fuse 8: Remote Liquid Solenoid Valve (PS2), Host Liquid Solenoid
Valve (PS3), Remote Defrost Hot Gas Solenoid Valve (PS4)
20 amps 10 amps
Fuse 9: Evaporator Fan Motor (EF3) 15 amps 10 amps
Fuse 10: Evaporator Fan Motor (EF4) 15 amps 10 amps
Fuse 11: Heaters 10 amps 7.5 amps
