Serial Number Locations
CONDENSER: Nameplate located on the back inside wall of
condenser frame.
ENGINE DRIVEN COMPRESSOR: Nameplate located on
compressor body. The engine driven compressor is located in
the truck engine compartment.
STANDBY COMPRESSOR: Nameplate located on
compressor body. The Standby compressor is located inside the
Condenser assembly.
1. Condenser Serial Number Location
2. Stand By Compressor Serial
Number Location
Figure 26: Condenser and Standby Compressor
Serial Number Locations
AMA511
2
