Inovance MS1 Series User Manual

1 Product Information
- 7 -
1.3 Speci󶍾cations
1.3.1 Mechanical Characteristics
Item Description
Running mode Continuous
Vibration level V15
Insulation resistance 500 VDC, above 10 MΩ
Ambient temperature 0ºC to 40ºC
Excitation mode Permanent magnetic
Installation method Flanged
Heat-resistance level Level H
Insulation voltage
1500 VAC 1 min (200 V)
1800 VAC 1 min (400 V)
Enclosure IP rating IP67 (excluding shaft opening
Ambient humidity 20% to 80% (no condensing)
Rotating direction
In forward RUN mode, the motor runs counterclockWise (CCW)
when viewed from the load side.
1.3.2 Ratings
Model
Frame Size
(mm)
Rated
Output
(kW)
[1]
Rated
Torque
(N·m)
Maximum
Torque
(N·m)
Rated
Current
(Arms)
Maximum
Current
(Arms)
MS1H1-05B30CB 40 0.05 0.16 0.56 1.3 4.70
MS1H1-10B30CB 40 0.1 0.32 1.12 1.3 4.70
MS1H1-20B30CB 60 0.2 0.64 2.24 1.5 5.80
MS1H1-40B30CB 60 0.4 1.27 4.46 2.8 10.10
MS1H1-55B30CB 80 0.55 1.75 6.13 3.8 15.00
MS1H1-75B30CB 80 0.75 2.39 8.36 4.8 16.90
MS1H1-10C30CB 80 1.0 3.18 11.1 7.6 28.00
MS1H2-10C30CB 100 1.0 3.18 9.54 7.50 23.00
MS1H2-10C30CD 100 1.0 3.18 9.54 3.65 11.00
MS1H2-15C30CB 100 1.5 4.90 14.7 10.8 32.00
MS1H2-15C30CD 100 1.5 4.90 14.7 4.50 14.00
MS1H2-20C30CD 100 2.0 6.36 19.1 5.89 20.00
MS1H2-25C30CD 100 2.5 7.96 23.9 7.56 25.00
MS1H2-30C30CD 130 3.0 9.8 29.4 10.00 30.00
MS1H2-40C30CD 130 4.0 12.6 37.8 13.60 40.80
MS1H2-50C30CD 130 5.0 15.8 47.6 16.00 48.00
MS1H3-85B15CB 130 0.85 5.39 13.5 6.60 16.50
MS1H3-13C15CB 130 1.3 8.34 20.85 10.00 25.00
MS1H3-85B15CD 130 0.85 5.39 13.5 3.30 8.25
MS1H3-13C15CD 130 1.3 8.34 20.85 5.00 12.50
MS1H3-18C15CD 130 1.8 11.5 28.75 6.60 16.50
MS1H3-29C15CD 180 2.9 18.6 37.2 11.90 23.80
