13
T
op Contr
ol Dishwasher
www.insigniaproducts.
com
Step 5: Install the 90° wa
ter supply elbow
1
Wrap the male thread of the 90° el
bow with
T
eflon thread seal tape.
Do not use plumber's putty
.
2
Install the 90° elbo
w onto the wa
ter valve
. Do not over
-tighte
n the 90° elbow
. T
he water v
alve bracke
t could bend
or the water valve fitting could break.
3
P
osition the end of the elbow to face th
e bottom right side of the dishwasher
.
Y
ou’ll need:
Adjustable wrench
90° elbow
T
eflon thread
seal tape
12
14
Table of Contents
Table of Contents
2
Introduction
2
Important Safety Instructions
2
Before You Begin
3
Preparing to Install Your Dishwasher
4
Enclosure Requirements
5
Drain Requirements
6
Drain Preparation
6
Electrical Requirements
7
Grounding Instructions
7
Cabinet Preparation and Wire Routing
8
Preparing the Hot Water Line
8
Connecting the Water Line to the Water Supply
9
Installation Instructions
10
Step 1: Check the Door Balance
10
Step 2: Remove the Toekick
10
Step 3: Adjust the Leveling Legs
11
Step 4: Install the Power Connection
11
Step 5: Install the 90° Water Supply Elbow
13
Step 6: Connecting the Water Supply Line
14
Step 7: Install the Drain Hose
15
Step 8: Inserting the Drain Hose through the Cabinet
16
Step 9: Slide the Dishwasher Partially into the Cabinet
16
Step 10: Position the Dishwasher under the Countertop
17
Step 11: Level the Dishwasher
18
Step 12: Securing the Dishwasher to the Countertop
19
Step 13: Connecting the Drain Hose
20
Step 14: Performing a Pre-Test Check
22
Step 15: Wet Testing the Dishwasher
22
Step 16: Replacing the Toekick
23
Specifications
23
