Step 11: Level the dishwasher
1 Open the door, then place a level on the door and on the rack track inside the tub to make sure that the dishwasher
is level.
2 Level the dishwasher by adjusting the three leveling legs individually.
3 If the edge of the door hits the side of the tub, the dishwasher is not installed correctly. Adjust the leveling legs to
align the door to the tub.
You’ll need:
Important: The dishwasher must be level for proper dish rack operation and wash performance.
Tip: Pull the lower rack out about halfway. Make sure that the rack does not roll forward or back into the dishwasher. If the rack rolls
in either direction, you must level the dishwasher again.
Note: The maximum adjustment height of the feet is 1.97 in. (50 mm)
Adjustable wrench
Level
Phillips screwdriver
Check side-to-side level
Check front-to-back level
Turn the legs to
adjust the level
