23
Top Control Dishwasher
www.insigniaproducts.com
Step 16: Replacing the toekick
• Place the toekick against the legs of the dishwasher. The slots should align with the toekick bracket screw holes.
Allow the toekick to touch the floor. Install the toekick screws.
Specifications
You’ll need:
Capacity Max 16 place settings
Dimensions (WxDxH) 23.9 x 24.5 x 33.8 in. (60.6 x 62.2 x 85.8 cm)
Weight 90.4 lbs. (41 kg)
Power requirements 120 V~60 Hz
Current 8.4 A
Water pressure Between 20 and 120 psi (138 and 877 kPa)
Noise (dB) 49 dB
