15
Table 1. Feature Summary (continued)
Nuvoton* Legacy I/O Controller (Nuvoton* W83677DHG) that provides:
ers
Ten USB 2.0 ports:
Four front panel ports (via two internal headers; one header supports an
Intel
®
Z-U130 USB Solid-State Drive (or compatible SSD))
Two ports are implemented with stacked back panel connectors (black)
Two high-current/fast-charging ports implemented through stacked back
panel connectors (yellow)
One port implemented in the PCI Express Half-Mini Card slot
One port implemented in the PCI Express Full-/Half-Mini Card slot
Two SATA ports:
One internal SATA connector (black)
One internal SATA connector (multiplexed with mSATA port , routed to PCI
Express Full-/Half-Mini Card slot) (gray)
Intel® 82579L Gigabit (10/100/1000 Mb/s) Ethernet LAN controller including an
RJ-45 back panel connector
Intel
®
BIOS resident in the Serial Peripheral Interface (SPI) Flash device
Support for Advanced Configuration and Power Interface (ACPI), Plug and
Play, and System Management BIOS (SMBIOS)
Instantly Available
PC Technology
Suspend to RAM support
Wake on PCI Express, LAN, front panel, serial, and USB ports
One PCI Express 1.0a x1 add-in card connector
One PCI Express Half-Mini Card slot
One PCI Express Full-/Half-Mini Card slot
Hardware Monitor
Subsystem
Nuvoton* W83677DHG based subsystem, including:
Hardware monitoring through the Nuvoton I/O controller
Voltage sense to detect out of range power supply voltages
Thermal sense to detect out of range thermal values
One 3-wire system fan header
One fan sense input used to monitor fan activity
Fan speed control
Support for Platform Environmental Control Interface (PECI)
