Intel Atom N2800 User Manual


17
Table 2 lists the components identified in Figure 1.
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1
Description
A
Debug connector
B
Battery
C
Back panel connectors (refer to Section 3.2.1)
D
System fan header
E
Internal power connector
F
Intel NM10 Express Chipset
G
BIOS Setup configuration jumper block
H
SATA data connector
I
SATA power connector
J
PCI Express Half-Mini card slot
K
SATA data connector
L
Intel processor N2800 and heatsink
M
Flat panel display connectors
N
DDR3 SO-DIMM 0 socket
O
DDR3 SO-DIMM 1 socket (Populate DIMM 1 when using a single SO-DIMM)
P
Front panel header
Q
Front panel audio header
R
Front panel dual-port USB headers
S
Standby power LED
T
Serial port headers
U
Parallel port header
V
DMIC header
W
PCI Express Full-/Half-Mini Card slot
X
Custom Solutions header
Y
PCI Express 1.0a x1 connector
Z
S/PDIF header
AA
Internal stereo speakers connector
Not marked in
diagram
Intel Z-U130 USB Solid-State Drive or compatible SSD

Intel Atom N2800 Specifications

General

Processor Number	N2800
Number of Cores	2
Number of Threads	4
Base Frequency	1.86 GHz
TDP	6.5 W
Instruction Set	64-bit
Lithography	32 nm
Launch Date	Q1'12
Instruction Set Extensions	SSE2, SSE3, SSSE3
Embedded Options Available	Yes
Max Memory Size	4 GB
Number of Memory Channels	1
Processor Graphics	Intel® Graphics Media Accelerator 3650
Graphics Base Frequency	640 MHz
Graphics Max Dynamic Frequency	640 MHz
Sockets Supported	BGA559
Max CPU Configuration	1
Idle States	Yes
Intel® 64	Yes
Intel® Identity Protection Technology	No
PCI Express Revision	2.0
Cache	1 MB
Memory Types	DDR3 800
PCI Express Configurations	1x4
