16 Simon XT User Manual
Using an offsite phone
If enabled by the installer, you can control your Simon XT panel remotely from an
offsite phone. The panel answers a phone call according to the dialing method
programmed by your installer.
After a certain combination of rings and pauses, the panel will answer the call
with the voice prompt Enter your code. You must enter the correct code to gain
access.
If you are interacting with your panel and the panel hangs up on you, the system
is calling in a report to the central monitoring station or remote phone due to an
action by you or someone at the security system site. The actions listed in
Table 6 below may be performed from an offsite phone.
Table 6: Phone controls
Action
Phone key presses
Comments
Disarm
1
System not already disarmed
Subdisarm
1
Must have used the master code to gain
access; system was disarmed
Arm doors and windows
2
Press 2 again to activate the no delay
feature
Arm motion sensors
3
Press 3 again to activate the latchkey
feature
Arm doors, windows, and
motion sensors
2 3
Check status
0
Turn light on
* –<unit_num>.
N = 1-8, unit number
Turn light off
# –<unit_num>.
N = 1-8, unit number
Turn all lights on
* – *
Turn all lights off
# – #
Hang up
9
Note: This feature is not verified for use by UL.
Using touchpads
Touchpads are used to control the security system from any location within or
near your home.
Touchpads such as the remote handheld touchpad and the keyfob, are not
verified for use by UL.

Interlogix Simon XT Specifications

Power

power requirements	6V nominal
standby current	30mA (10mA in PowerSave Mode)
peak current	1.7 A

Operating Environment

operating temperature	32 to 120°F (0 to 49°C)
storage temperature	-30 to 140°F (-34 to 60°C)
max. relative humidity	90% non-condensing

Dimensions

height	4 1/16 in.
width	1 7/8 in.
