Invacare Comet Series User Manual

Service
Component
CheckRemedy
Notes
Checkstatusdisplay
(ashing)
Evaluateashcode
CheckxingTightenorreplace
xing
Checkcable,
connectingplug
Replacecable,
connectingplug
Checkdrivelever
function
Replacedrivelever
Drivecontrols
CheckpowersupplyReplacecable,
connectingplug
orconsole
Driveprogram
Checkdrive
programversion.
Newversion
available?
Updatesoftware
Checkcableand
connectingplug
Adjustorreplace
sensoroncurve
controldevice
Curvecontrolinbends
Checkfunction
Screws
Checkscrewsfor
tightt
Tightenscrewsif
necessary
4.5Controls
4.5.1Replacingoperatingconsole
CAUTION!
Riskofburnsifpowercableisshorted
–Turnoffthepowercompletelybeforeremoving
anypowersupplycomponentsofmobility
device.Thereforetakeoutbatteries.
–Avoidbridgingofcontactsduringmeasurements
onliveelectricalcomponents.
Riskofdamagetooperatingconsole/circuit
boardbyinstanthighcurrent/voltage
–Unplugbatterycablebeforeremoving/installing
operatingconsole.
–Makesureallpinsarecorrectlyconnected.
Theplugsontheoperatingconsolecannotbe
wronglyconnectedbecauseallplugshaveadifferent
sizeandonlytinonesocket.
•Phillipsscrewdriver
Settingbatterygaugeismandatorywhenretrotting
operatingconsole.
Settingwheeldiameterismandatorywhen
retrottingoperatingconsole.
1.Removeseat.
2.Removeshroud.
3.
DisconnectbatterycableA.
4.
RemovetopshroudAfromsteeringcolumnB.
1603798-B
11
