Invacare Comet Series User Manual

Service
Installation
1.Installpartsinreverseorder.
CAUTION!
Reducedfunctionwhenclutchismounted
incorrectly
–MakesuretomountclutchAwith
inscription“M”facingmotor .
CAUTION!
Nobreakingefcencywithoutfeatherkey
–MakesuretomountfeatherkeyBon
motorshaftAwhenreassembling.
2.TightenscrewBonswingarmto15Nm.
3.Checkallfunctions(trialrun).
4.10.2Replacingcarbonbrushes
Alwaysreplaceallthecarbonbrushesonboth
motors.
•5mmAllenkey
•6mmAllenkey
•10mmsocketwrench
•19mmsocketwrench
Bladescrewdriver
Longwoodenblocks,min.14x14x30cm
Removingcarbonbrushes
1.Switchoffmobilitydevice.
2.Removedrivewheels.
3.DisengagemotorAbysettingtheengagingleverto
“Push“.
4.LoosenandremoveallfourplasticcapsB.
Notethexingpositionandlocationofthe
carbonbrushes.
Usedcarbonbrushesneedtotherettedexactly
inthesamepositionfromwhichtheyweretaken
inordertoguaranteeoptimumcontacttothe
collector .
5.Makeamarkingonthemotorandthecarbonbrushes
inordertoguaranteecorrectinstallation.
6.RemovecarbonbrushescompletelyfrommountingC.
7.Checkcarbonbrushandspringforlevelofwear,broken
componentsordiscolouration.
Installingcarbonbrushes
1.Dependingonconditionofbrushandspring:-either
installbrushesinexactlythesamepositionfromwhich
theyweretakenor-tnewbrushes.
2.Installplasticcapsandtightenthemrmly.
3.Installdrivewheels..
Thefollowingprocedureisnecessarytorun
carbonbrushesinafterreplacementandthus
guaranteemaximumperformance.
CAUTION!
Riskofaccidents
Injuriestoworkers,damagetosurroundings
andmobilitydevice.
–Donotleavemobilitydeviceunattended
duringthefollowingprocedure.
–Securearea.
4.Liftmobilitydeviceupononesideandgetasecond
persontoplaceawoodenblockaround14cmhigh
underneathitsothatthedrivewheelissuspended
freely.
5.Repeatonothersideofmobilitydevice.
6.Allowmotorstorunforanhourinforwarddirection.
7.Allowmotorstocooldownfor30minutes.
8.Allowmotorstorunforanhourinreversedirection.
9.Liftmobilitydeviceoffwoodenblocks.
4.11Seatsystem
4.11.1Replacingseatsuspension/spring
CAUTION!
Riskofaccident
Accidentalrollingcanleadtoaccidents.
–Securethescooteragainstrollingaway.
Whendisassembling,notethepositionofsmallparts
suchasscrewsandwashers.Putsmallpartsdownso
thattheycanbereassembledintherightsequence.
Thefollowingseatsupporttubeslengthsareavailablefor
theseatsuspension:
•508.5mm
•533.5mm
•558.5mm
•17mmwrench(2x)
1.Securescooteragainstrollingaway.
2.Removeseat.
1603798-B31
