Invacare Comet Series User Manual

Comet
6.
Removescrews(3)onindicatorglass.
7.Removeindicatorglass.
8.Loosenscrews(4)onorange-coloredcap(5)andremove
cap.
9.Replacelightbulb.
10.Installpartsinreverseorder.
11.Testfunctions.
4.7.3Replacingcenterbrakelight
CAUTION!
Riskofburnsifpowercableisshorted
–Turnoffthepowercompletelybeforeremoving
anypowersupplycomponentsofthemobility
device.Thereforetakeoutthebatteries.
–Avoidbridgingofcontactsduringmeasurements
onliveelectricalcomponents.
Whendisassembling,notethepositionofsmallparts
suchasscrewsandwashers.Putsmallpartsdownso
thattheycanbereassembledintherightsequence.
•Phillipsscrewdriver
1.Removeseat.
2.Removeshroud.
3.
DisconnectbatterycableA.
4.
Disconnectplug(4).
5.
RemoveboltsAonrearshroud.
6.Liftrearshroudupwards.
7.
Removescrews(1)onbrakelight.
8.Replacebrakelight.
9.Installpartsinreverseorder.
10.Testfunctions(trialrun).
4.7.4Replacingrearlights/directionindicators
CAUTION!
Riskofburnsifpowercableisshorted
–Turnoffthepowercompletelybeforeremoving
anypowersupplycomponentsofthemobility
device.Thereforetakeoutthebatteries.
–Avoidbridgingofcontactsduringmeasurements
onliveelectricalcomponents.
Whendisassembling,notethepositionofsmallparts
suchasscrewsandwashers.Putsmallpartsdownso
thattheycanbereassembledintherightsequence.
201603798-B
