Service
•Phillipsscrewdriver
1.Removeseat.
2.Removeshroud.
3.
DisconnectbatterycableA.
4.
RemoveboltsAonrearshroud.
5.Lifttherearshroudupwards.
6.
Removescrews(1)onrearlight.
7.Removerearlight.
8.
Removescrews(1)onrearlightglass.
9.
Removerearlightglass(1).
10.Replacelightbulbs(2).
11.Installpartsinreverseorder.
12.Testfunction.
4.8Wheels
4.8.1Replacingwheelsuspension
CAUTION!
Riskofaccident
Accidentalrollingcanleadtoaccidents.
–Securescooteragainstrollingaway.
Whendisassembling,notethepositionofsmallparts
suchasscrewsandwashers.Putsmallpartsdownso
thattheycanbereassembledintherightsequence.
•32mmwrench
•Phillipsscrewdriver
•Supportingwoodenblock
1.Removeseat.
2.Removeshroud.
3.
DisconnectbatterycableA.
4.Dismantlesteeringlinkandcouplingrod.See4.9.3
Replacingsteeringlink/couplingrod,page27.
1603798-B
21
