Function and Features

Chapter III Function and Features

This chapter will introduce the basic operation of IT6700 series power supply,

including the following subdivisions:

⚫ Switching of local/remote operation modes

⚫ Voltage setup

⚫ Current setup

⚫ Output on/off operation

⚫ Setup value/actual value switching

⚫ Voltage/current/power adjustment

⚫ Save/recall operation

⚫ Trigger operation

⚫ Menu operation

⚫ OVP protection function

⚫ Key lock function

⚫ Remote sense function

3.1 Switching of local/remote operation modes

Local button can enable you switch mode from remote to local mode.

After you power on the power supply, the power supply’s default mode is local

mode, all the buttons can be used in this mode. While in remote mode, you

can’t operate through front panel directly except Meter and Local keys. Local

and remote mode can be controlled through PC. In addition, the mode

changing will not influence the output parameters.

3.2 Voltage Setup

You can set voltage within the range of rated voltage value. When you press

button, the button will be lit. This indicates that you can set voltage.

There are three ways to set output voltage through front panel.

⚫ The first way: press , adjust cursor location through

button, pressing and will enable you to adjust the setting voltage

value.

⚫ The second way: press , adjust cursor location through

button, adjust rotary knob to change the setting voltage value.

⚫ The third way: press button and number key( to ) to set

voltage value

3.3 Current Setup

You can set current within the range of rated current value. When you press

button, the button will be lit. This indicates that you can set current.

There are three ways to set output current through front panel.

⚫ The first way: press ,adjust cursor location through

V-setV-set

I-setI-set
