Function and Features
Copyright © Itech Electronic Co., Ltd. 28
10. VFD display REPET 1,press number key to or rotary knob to set
the repeat times, press to confirm.
11. VFD display SAVE >NO, press to confirm, in this circumstance,
the list file is not saved but can run for one time, or you can press
button to select >SAVE FILE0,saving the list test file in FILE0~FILE9,press
to confirm. You can recall the file in the following utilization.
12. If you do not save the list test file, VFD will display LIST EDIT; if you select
to save the test file, VFD will display SAVE DONE for three seconds, and
then display LIST EDITL.
Set List State
13. Press to select >LIST STATE item, press to confirm.
14. VFD display LIST >OFF, press to select >LIST >ON, press to
confirm. Now button will be lit. This indicates that list operation
function has been opened.
15. VFD display >LIST STATE, pressing button can quit the operation.
Run list file
16. Press button to open the output, press (Shift)+
(Trigger)to give a trigger signal.
Recall list file
17. If you have edited several list files, you can select LIST LOAD item to recall
the file you need. And then press to quit this operation. Press
button to open the output. Now you only need to press
(Shift)+ (Trigger) to give a trigger signal, the list file can be ran.
Quit list file
18. In LIST mode, voltage set and current set button can’t be used, In LIST
STATE item, choose LIST>OFF will enable you to quit list mode.
3.10 Protective function
The power supply is provided with following protective functions: over-voltage
protection (OVP), over-current protection (OCP), over-temperature protection
(OTP) and sense reverse protection (SRV).
