Jacuzzi J-200 Series User Manual

16
6.0 Understanding Circuit Board Pin Assignments
6.1 Circuit Board Jumpers (All North American 60 Hz 1-Pump Models)
All North American 1-pump circuit boards can be congured for either 15/30A or 40A operation (40/50A for
J230 models). Refer to jumper pin table and circuit board diagrams for specic system details.
6.2 Circuit Board Jumpers (All North American 60Hz 2-Pump Models)
All North American 2-pump circuit boards can be congured for either 40, 50A, or 60A operation. Refer to
jumper pin table and circuit board diagram below for specic system details (factory jumper settings shown):
MODEL
Circ
Pump
BOARD
LOG-
IC
6600-042 6600-046 6000-167 6600-287 6600-288 6600-289 6600-720 6600-722
J-280 (2013+) No X X 5.59+
J-280 (2012) No X 5.59+
J-280 (2012) Yes X 3.60+
J-280 (2011) No X 5.57+
J-280 (2011) Yes X 3.57+
J-275 (2012+) No X X 5.59+
J-270 (2012) No X 5.59+
J-270 (2012) Yes X 3.60+
J-270 (2011) No X 5.57+
J-270 (2011) Yes X 3.57+
J-245 (2012+) No X X 5.59+
J-235 (2012+) No X X 5.59+
J-230 (2012) No X 5.59+
J-230 (2012) Yes X 3.60+
J-230 (2011) No X 5.57+
J-230 (2011) Yes X 3.57+
J-210 (2012+) No X X 5.57+
J-210 (2011) No X 5.57+
MODEL
CIRCULATION
PUMP
BOARD
LOGIC
6600-726 6000-167 6600-044 6600-286 6600-288
J-LX (2011+) Yes X X 3.60+
J-LX (2011+) Yes X X 3.60+
J-375 (2012-2013) Yes X 3.60+
J-375 (2011) Yes X 3.57+
J-365 (2012-2013) Yes X 3.60+
J-365 (2011) Yes X 3.57+
J-355 (2012-2013) Yes X 3.60+
J-355 (2011) Yes X 3.57+
J-345 (2012-2013)
Yes X 3.60+
J-345 (2011) Yes X 3.57+
J-335 (2012-2013) Yes X 3.60+
J-335 (2011) Yes X 3.57+
J-325 (2012-2013) Yes X 3.60+
J-325 (2011) Yes X 3.57+
J-315 (2012-2013) Yes X 3.60+
J-315 (2011) Yes X 3.57+
