7.4 Some Controller Buttons Do Not Operate
Yes
Yes
No
Press button that
does not operate.
Does the display
read Locked?
Go to the
Power Cen-
ter and look
at the LED
above the
button. Is the
LED on?
Some buttons on
Controller do not
operate (LEDs
for those buttons
don't light).
Press Reset button
on left side of Con-
troller. The second
number and Revi-
sion letter is that of
the Power Center
fi rmware chip.
Does the Part#
for fi rmware chip
match the model of
AquaLink RS? See
chart below.
Press Cancel Button, then
select Lockouts, then se-
lect Device to unlock.
Contact Jandy for cor-
rect fi rmware chip.
Yes
No
Replace Con-
troller PCB.
Replace Power Cen-
ter fi rmware chip.
No
Table 7. Models, Descriptions and Part Numbers
Model Description
Part #
Rev. C to
Rev II
Part #
Rev J to
Rev MMM
Part #
Rev N and
Later
AquaLink RS 16, 24, 32 P & S Pool and Spa Combination 7202 8166
E0260811
AquaLink RS 12 P & S Pool and Spa Combination 7201 8165
E0260810
AquaLink RS 8 P & S Pool and Spa Combination 6520 8156
E0260801
AquaLink RS 6 P & S Pool and Spa Combination 6521 8157
E0260802
AquaLink RS 4 P & S Pool and Spa Combination 6522 8158
E0260803
AquaLink RS 16, 24, 32 P or S Pool or Spa Only System 7215 8168
E0260813
AquaLink RS 12 P or S Pool or Spa Only System 7214 8167
E0260812
AquaLink RS 8 P or S Pool or Spa Only System 6523 8159
E0260804
AquaLink RS 6 P or S Pool or Spa Only System 6524 8160
E0260805
AquaLink RS 4 P or S Pool or Spa Only System 6525 8161
E0260806
AquaLink RS 2/14, 2/22, 2/30 Dual Separate Equipment System 7217 8170
E0260815
AquaLink RS 2/10 Dual Separate Equipment System 7216 8169
E0260814
AquaLink RS 2/6 Dual Separate Equipment System 6526 8162
E0260807
