27
MC450e
Adjusting the Y-carriage Supporter
Adjustment
1. Remove the carriage cover (refer to page 6).
2. Loosen the setscrew (A).
Adjust the distance between the top of the rail and the
lower edge of Y carriage to 14.3±0.3 mm.
3. Tighten the setscrew (A).
4. Attach the carriage cover.
Y-carriage supporter
Setscrew (A)
14.3±0.3 mm
Lower edge of Y-carriage
Top of the rail
The distance between the top of the rail and the lower edge of Y-carriage should be in the
range of 14 to 14.6 mm.
