JBL ON AIR WIRELESS User Manual

5www.jbl.com
English
REMOTE CONTROL BUTTONS
Volume Up/DownPower
Up
Home
Left
Down
Previous
Snooze
Soft Buttons
Mute
Right
OK
Play/Pause
Next
Alarm Off
• Previous, Play/Pause and Next buttons: When listening to AirPlay
or an iPod device, press these buttons to skip to the previous song,
play/pause the current song, or skip to the next song.
• Mute button: Press this button to mute the sound; press it again to
restore the sound.
• Alarm Off button: Press this button to shut off the alarm sound until
the next time the alarm is scheduled to ring.
The remaining remote control buttons perform the same functions as
their counterparts on the JBL On Air Wireless unit.
Before using the remote control, remove the battery contact-protection
strip by pulling on the tab.
Changing the remote control’s battery:
1. Press the tab on the side of the battery tray and pull the tray out of
the remote.
2. Place a model CR2025 battery into the tray with the positive (+)
terminal facing as shown in the illustration, and replace the battery
tray in the remote.
CR2025
Battery
1. 2.

JBL ON AIR WIRELESS Specifications

General

Impedance	10000 Ω
Frequency range	20 - 20000 Hz
RMS rated power	7 W
Audio output channels	- channels
Signal-to-Noise Ratio (SNR)	90 dB
Bluetooth	No
DC-in jack	Yes
Wi-Fi standards	802.11b, 802.11g
Headphone connectivity	-
Apple docking compatibility	iPhone, iPod
Battery voltage	12 V
Power source type	Battery
Product color	Black
Volume control	Digital
Dimensions (WxDxH)	280 x 198 x 238 mm

Weight and Dimensions

Depth	198 mm
Width	280 mm
Height	238 mm
Weight	1690 g
