Amplifier/Subwoofer PSW-D110/DPS-10
PSW-D110/DPS-10 MECHANICAL PARTS LIST
Ref.# PartNumber Description Qty Ref.# PartNumber Description Qty
PSW-D110/DPS-10
3 70307 AIR LEAK COVER 1
4 70308 SAFETY PART PSW-D110 LED SOCKET 1
5 70150 PHASE SWITCH 1
6 70170 SCREWS TO SECURE INPUT JACKS 3
#4X.5" MACHINE SCREW
7 70171 BOLTS FOR TRANSFORMER 4
#10 X 1 MACHINE SCREWS
8 70172 NUTS FOR TRANSFORMER 4
#10 KEPS NUT
9 70173 SCREWS FOR FUSE PCB 2
#6 X .5"
10 80113 TRANSFORMER #4472 SAFETY PART 1
11 80114 250V, 1.25A, T type SLO BLO fuse 1
SAFETY PART
108115 HIGH LEVEL INPUT AND OUTPUT 1
TERMINALS
108321 QUAD RCA INPUT JACKS 1
200500 PSW-D110 10" WOOFER 1
PSW-D110 (Only)
1 70302 KNOBS PSW-D110 2
2 70310 PWS-D110 FACEPLATE 1
200510* GRILLE COMPLETE PSW-D110 1
200511*
200520 CARTON PSW-D110 1
200530 120V PSW-D110 OWNER'S MANUAL 1
AMPLIFIER PSW-D110 1
200560 CONTROL PANEL PSW-D110 1
40402 VOLUME CONTROL AND HARNESS 1
PSW-D110
200580 LED AND HARNESS PSW-D110 1
200582 FOOT 4
DPS-10 (Only)
1 70302 KNOBS DPS-10 3
2 70306 FACEPLATE DPS-10 1
200620 CARTON DPS-10
200621 TOP STYRO RAIL(2) PER BOX DPS-10
200622 BOTTOM STYRO RAIL(2) PER BOX DPS-10
200630 120V DPS-10 OWNER'S MANUAL
200640 PLASTIC BAG DPS-10
AMPLIFIER DPS-10
200670 FOOT
* For grille replacement, there are two versions of the grille. Earlier version has a .220" (5.6mm) grille pin diameter. JBL Part#
200510. Later version has a .410" (10.4mm) grille pin diameter. JBL Part# 200511. In the case of a missing grille, where pin
diameter cannot be measured: take approximate diameter from the rubber grille cups in the subwoofer cabinet.

JBL PSW-D110 Specifications

Power

power output (RMS)	150 watts

Driver

driver size	10"
driver material	High-Polymer Laminate

Inputs and Outputs

inputs	Line Level and Speaker Level
outputs	Line Level and Speaker Level

Frequency

frequency range	60Hz – 180Hz
frequency response	30Hz – low-pass crossover setting

Weight and Dimensions

dimensions	15-3/8 x 15-3/8 x 17" / 391 x 391 x 432mm
weight	33 lbs / 15 kg
