JBL PSW-D110 User Manual

DETAILED SPECIFICATIONS
LINE VOLTAGE
Yes/No
Hi/Lo Line Unit Notes
US 120vac/60Hz
Yes
108-132 Vrms Normal Operation
EU 230vac/50-60Hz
Yes
207-264 Vrms Normal operation, MOMS required
Parameter Specification Unit Conditions Notes
Amp Section
Type (Class AB, D, other)
D
Class D Preferred...Sink required for Class AB
Load Impedance
(speaker)
4
Ohms Nominal Z-curve required
Rated Output Power
150
Watts 1 input driven Peak power
75
Watts 1 input driven RMS
THD@ Rated Power
0.1
% 22k filter 75w (Power Bandwidth 30-100Hz)
THD @ 1 Watt
0.1
% 22k filter
DC Offset
2
mV-DC @ Speaker Outputs
Damping factor
>200
DF
Input Sensitivity
Input Frequency
50
Hz Nominal Freq. 1 input driven
Line Input
110
mVrms To Rated Power/ Vol @ Max 1 input driven
Speaker/Hi Level Input
2.7
Vrms To Rated Power/ Vol @ Max 1 input driven: AP sourceZ=25ohms
Signal to Noise
SNR-A-Weighted
100
dBA
relative to 75w power
A-Weighting filter
SNR-unweighted
75
dBr relative to 75w power 22k filter
SNR rel. 1W-unweighted
65
dBr relative to 1W Output 22k filter
Residual Noise Floor
2
mVrms Volume @max, using RMS reading DMM/VOM (or A/P)
Residual Noise Floor
1.5
mVrms(max) Volume @max, w/ A/P Swept Bandpass Measurement (Line freq.+ harmonics)
Input Impedance
Line Input
10k
ohms Nominal
Speaker/Hi Level Input
200
ohms Nominal
Filters 0dBr = 1w @ 50Hz
Low Pass (fixed or
variable)
Variable
Low Pass filter (point or
range)
60-120
Hz -3dB Point
Slope
18
dB/Octave
Q
1
Damping
Subsonic filter (HPF)
25
Hz -3dB Point
Slope
12
dB/Octave
Q
1
Damping
4
Amplifier/Subwoofer PSW-D110/DPS-10

JBL PSW-D110 Specifications

Power

power output (RMS)	150 watts

Driver

driver size	10"
driver material	High-Polymer Laminate

Inputs and Outputs

inputs	Line Level and Speaker Level
outputs	Line Level and Speaker Level

Frequency

frequency range	60Hz – 180Hz
frequency response	30Hz – low-pass crossover setting

Weight and Dimensions

dimensions	15-3/8 x 15-3/8 x 17" / 391 x 391 x 432mm
weight	33 lbs / 15 kg
