63 - 2
Power Take Off Clutch
Removal and Replacement
Removal
Note: If the PTO clutch is to be dismantled, the drive yoke
stake nut 4 should be loosened before the clutch is removed
from the gearbox.
Disconnect the hydraulic pipe connection from the PTO
housing. Plug the exposed connections to prevent ingress of
dirt.
Loosen and remove the 8 bolts 1 which secure the PTO
housing 2 to the gearbox.
Carefully lift the PTO clutch from the gearbox. Remove and
discard gasket 3.
Replacement
Replacement is the reverse of the removal procedure.
Torque tighten bolts 1.
When fitting stake nut 4, torque tighten as indicated then
split the nut sleeve axially using a square ended staking tool.
(This operation may be easier performed after the clutch has
been replaced in the gearbox.)
Torque Settings
Item
1 56 Nm 41 lbf ft 5.7 kgf m
4 350 Nm 258 lbf ft 35.7 kgf m
Section F Transmission
9803/7130
Section F
63 - 2
Issue 1
Syncro Shuttle Gearbox
