Jotron AS| TR7750C: Operators Manual Operating Instructions
P/N: 84748 (G)
Menus for user level: Technician
For details regarding submenus, refer to chapter 5.4.
Menus for user level: SysOp
For details regarding submenus, refer to chapter 5.4.
Table 5.7-1, User menu selections receiver - Operator, Technician and SysOp access levels
5.8 Setting, information and configuration menus – receiver
Under the menu selection from the user menu, various submenu groups are available depending on
the user level.
The submenus and details for them are shown in the tables below.
Access to operation mode, low power level, climax offset
parameters, modulation and standby settings.
Access to configuration parameters for modulation, audio
settings, Squelch settings and internal calibration settings.
Access to configuration parameters for the ethernet
interface, RS232 port, RS485 port, various pin settings on
the hardware interface (remote connectors) and the user
access level.
Displays information about active alarms and gives the
user access to internal measurements.
Displays information about the firmware and hardware
release, system up-time and radio identification
Table 5.8-1, Submenus available on the receiver
