– 18 –
3. Operating procedure of the sewing pattern
Without reverse
stitching
Reverse
stitching
Double reverse
stitching
(Caution) 1. For the operation panel other than CP-18, refer to the Instruction Manual for the operation
panel to be used.
2. For some machine heads, reverse-stitching pattern cannot be used.
(1) Reverse feed stitching pattern
Reverse feed stitching at sewing start and reverse feed stitching at sewing end can be separately pro-
grammed.
[Setting procedure of the reverse feed
stitching]
1) Effective/ineffective of the reverse
feed stitching pattern can be changed
over by pressing switch
1
.
When the reverse feed stitching pat-
tern is rendered effective, LED
C
lights up, the number of stitches of
the reverse feed stitching at sewing
start is displayed on
A
, and the num-
ber of stitches of the reverse feed
stitching at sewing end is displayed
on indicator
B
.
2) When the number of reverse feed
stitches display is not ashing on and
off, every press on switch
3
changes over the reverse feed stitch-
ing mode from the "reverse feed
stitching at sewing start," "double
reverse feed stitching at sewing
start" and "no reverse feed stitching
at sewing start."
In addition, every time switch
5
is pressed, the reverse feed stitch-
ing feature changes over from the
reverse feed stitching at sewing end
to the double reverse stitch at sewing
end, then to no reverse feed stitching
at sewing end, in turn.
Select a process (A, B, C or D) the number of stitches for which is to be changed by using switch
4
.
The number which is ashing on and off represents the process which is being set.
Change the number of stitches for the selected process by using switch
5
and switch
6
.
Press switch
3
to conrm the
change you have made. (The number of stitches that can be set is 0 to
15.)
(Caution) The sewing machine cannot perform sewing when the display of the number of stitches for a
processisashingonandoff.
6
543
1
B
A
2
7
C
D
6
543
1
2
7
B
A
C
D
