– 2 –
1
2. Installing the motor unit
Install the motor unit on the table with the tting bolt
asm. supplied with the unit as accessories.
At this time, insert the nuts and washers supplied
with the unit as accessories as shown in the gure
so that the motor unit can be securely xed on the
table.
1) Press three bolts
1
supplied with the unit as ac-
cessories into the motor hanging bolt hole in the
table and x them.
2) Temporarily tighten convex washer, spring
washer and nut on the side where two bolts are
attached.
3) Hang the motor unit to the washer which has
been temporarily tightened, and attach convex
washer, spring washer and nut to the other bolt
on the opposite side.
4) After adjusting the installing position of the motor,
securely tighten the respective nuts.
3. Installing the control box
2) Loosen four screws
2
supplied with the mo-
tor unit as accessories, tighten screws
2
after
hanging control box unit
3
to the screws, and x
control box unit
3
.
Spring washer
Nat
Convex washer
2
3
1
1) Attach bracket
1
supplied with the unit using
four supplied screws (M5 x 10) as shown in the
gure.
To use the SC-922 with the belt-drive type machine head, install the control box on the motor unit according
to the following instruction.
