KNX Room actuator 230 V
Ref.-no.: RA 23024 REGHE
3
commissioning software from version ETS3.0d onwards.
The product database, technical descriptions, conversion programs and
other utilities are available in their latest version on our Internet page.
3.2 Designated use
• Switching of electrical consumers AC 230 V with potential-free contacts
• Switching of electrically operated blinds, shutters, awnings and similar
curtains
• Heating outputs: electronic outputs for switching electro-thermal valve
drives
• - Installation on DIN rails in small distribution boards
Product features
• Manual output control, provisional operation
• Feedback in manual control mode and in bus operation
• Scene function
• Disabling of individual outputs by hand or via the bus
Switching function
• Make-contact and break-contact operation
• Logic operation and forcing function
• Feedback function
• Central switching function with group feedback
• Time functions: ON-delay, OFF-delay, staircase lighting timer with early-
warning function
Blind/shutter function
• Suitable for AC motors 230 V
• Direct control of blind/shutter position
• Direct control of slat position
• Checkback of running state, blind/shutter position and slat position
• Forced-control position from primary control
• Safety function: 3 independent wind alarms, rain alarm, frost alarm
• Sun protection function
Control of valve drives
• Switching or PWM operation
• Control of valve drives with working characteristics „normally open“ or
„normally closed“
• Overload and short-circuit protection
• Emergency operation in the event of bus failure for summer and winter
• Protection against jamming valves
• Forced-control position
• Cyclical monitoring of input signals parametrizable
L PWM operation: Electro-thermal valve drives only have an „open“ and a
„closed“ position. In PWM operation, these devices have quasi-
continuous characteristics due to fast switching within the cycle time.
