Juniper J-Series Getting Started Guide

Table 66: RS-232 DTE Cable Pinout (continued)
DescriptionLFH-60 PairingDB-25 PinLFH-60 Pin
Terminal Clock–2452
–––22 to 21
–––18 to 17
RS-232 DCE Cable Pinout
Table 67: RS-232 DCE Cable Pinout
DescriptionLFH-60 PairingDB-25 PinLFH-60 Pin
Frame Ground–115
Transmit Data–21
Receive Data–360
Request to Send–437
Clear to Send–548
Data Set Ready–633
Signal Ground–757
Data Carrier Detect–813
Transmit Clock–1556
Receive Clock–1752
Local Loopback–1845
Data Terminal Ready–209
Terminal Clock–245
–––22 to 21
RS-422/449 (EIA-449) DTE Cable Pinout
Table 68: RS-422/449 (EIA-449) DTE Cable Pinout
DescriptionLFH-60 PairingDC-37 (DB-37) PinLFH-60 Pin
Shield Ground–115
Serial PIM Cable Specifications ■ 227
Chapter 13: Network Cable Specifications and Connector Pinouts
