Step 2: Install the Mounting Hardware in a Four-Post Rack or Cabinet or an Open-Frame

Rack

To install the mounting shelf on the front rails of a four-post rack or cabinet, or the rails

of an open-frame rack:

1. If needed, install cage nuts in the holes specified in Table 1 on page 6.

2. On the back of each rack rail, partially insert a mounting screw into the lowest hole

specified in Table 1 on page 6.

3. Install the mounting shelf on the back of the rack rails. Rest the bottom slot of each

flange on a mounting screw.

4. Partially insert screws into the open holes in each flange of the mounting shelf (see

Figure 2 on page 7 or Figure 3 on page 8).

5. Tighten all the screws completely.

Table 1: MX480 Mounting Hole Locations

Mounting ShelfDistance Above U DivisionHole

X1.14 U2.00 in. (5.1 cm)4

X0.86 U1.51 in. (3.8 cm)3

X0.50 U0.88 in. (2.2 cm)2

X0.14 U0.25 in. (0.6 cm)1

MX480 3D Universal Edge Router Quick Start
