40
Using a Keyboard to Control Recording
Recording operations of this DVD recorder can be carried out using the REC CONTROL panel displayed on the monitor. In
addition, a keyboard can also be used when working with this panel.
Signal Connections
Connect a keyboard to the USB terminals on the back of the DVD recorder.
Settings
● If the REC CONTROL panel is to be displayed on-screen, set REC CONTROL
from the REMOTE MENU screen to ON.
This panel will be displayed in Stop, Recording, and Recording Pause mode.
To open the Setup Menu, press the DVD recorder’s SET UP button. Or, press
the ESC key on the keyboard, and the set up menu will be displayed.
Procedure
1.
Start recording.
Keyboard : Use the arrow keys (©, †, ∞, and √) to select Record (r) from
the REC CONTROL panel, and then press the Enter key.
2.
Pause recording.
Keyboard : Use the arrow keys (©, †, ∞, and √) to select Pause (w) from
the REC CONTROL panel, and then press the Enter key.
● The DVD recorder will adopt Recording Pause mode; in addition, a chapter
mark (index) and thumbnail will be inserted at the current position.
3.
Restart recording.
Keyboard : Use the arrow keys (©, †, ∞, and √) to select either Record (r)
or Pause (w) from the REC CONTROL panel, and then press the
Enter key.
Steps 2 and 3 can be repeated to create a single, partitioned title.
4.
End recording (i.e., close the title)
Select Stop (q) from the REC CONTROL panel and press the Enter key.
● The action of the DVD recorder following the end of recording depends on
the setting of EDIT MENU from the DVD MENU screen.
DISABLE : Recording is ended and the chapter menu is created using
standard settings (i.e., the title is closed).
ENABLE : The THUMBNAIL EDIT screen will appear. This screen can be
used to modify the chapter menu’s display style, to change the
thumbnails used, to input chapter names, and to perform other
similar functions. For more details, refer to page 43.
If additional recording is to be carried out, repeat steps 1 through 4 above.
● In such a case, each subsequent recording will be stored as a new title.
5.
End recording and remove the disc.
Depending on how the disc will be used, one of two different procedures
is implemented at this time.
● If more content will be recorded to the disc using this DVD recorder:
Simply press the DVD recorder’s OPEN/CLOSE button and remove the disc.
(Do not finalize the disc before it is removed.)
● If the disc is to be played on a different DVD player:
Use FINALIZE from the REC CONTROL panel to finalize the disc before it is
ejected.
For more details regarding finalizing, refer to page 42.
000 min
04/05/04
11:20:00
TITLE 01 0:11:22
CHAPTER
01 0:11:22
REC
FINALIZE
DISC
TITLE
REMOTE MENU screen
REC CONTROL panel
Notes
● DISC TITLE from the REC CONTROL
panel can be selected to allow a name
to be input for the disc. This type of
name proves useful when managing
discs using a PC. Note that disc names
are not displayed on the monitor or the
DVD recorder.
Characters allowed for the disc title are
alphanumerical characters and
underscore (_) only. Space and other
symbols may not be used.
● FINALIZE and DISC TITLE from the
REC CONTROL panel cannot be used
while recording.
● The Record (r) button from the REC
CONTROL panel can be activated or
clicked to insert chapter marks (indexes)
and thumbnails during recording.
Esc F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11 F12
Print
Screen
Sysrq
Scroll
Lock
Pause
Break
Tab
Caps Lock
Shift Shift
Ctrl CtrlAlt Alt
Enter
Back
Space
Insert
Delete End
Home
Page
Up
Page
Down
Enter
0
12
56
+
-
4
897
.
/
*
Num
Lock
1
Q
A
ZXCVBNM
<>
? ＿
SDFGHJ KL
U
WE R T Y I O P
234567890
-
^
@
￥
「
「
;
:
、
。
/
・
.
/
,
｀
[
]
」
＋
＊
！ # $ % & =(
)
'
〜
VIDEO
POWER
MAIN
FOR SERVICE
FOOT SW
AUDIO
REMOTE
IN
IN
OUT
USB
1
2
+
4dB
-
8dB
OUT
DV IN/OUT
LINE
CH1
CH2
INPUT
LEVEL
Y/C
AC IN
Y/C
MENU
REMOTE SELECT
FOOT SW1
OFF
OFF
ON
OFF
REC CONTROL
FOOT SW2
232C BAUDRATE
9600
TYPE1
232C PROTOCOL TYPE
REMOTE MENU
Recording
