2
MECHANISM ASSEMBLY <M3>
!
REF.
MODEL
GR-SXM340U GR-AXM236UC GR-AXM240UC GR-SXM240U GR-SXM245U GR-SXM245UC GR-SXM248UC
No.
ITEM
400 MECHA(B)ASSY YMA0034A-E YMA0033A-E YMA0034A-E
406 CASSETTE GUIDE ASSY(RIGHT) YQ44339A-7 ——YQ44339A-7
406A SW.LEVER(RIGHT) YQ32162-1-3 ——YQ32162-1-3
406B TORSION SPRING YQ44340-1-4 ——YQ44340-1-4
407 SCREW LY42819-001A ——LY42819-001A
466 ROTARY ENCODER QSW0888-002 QSW0888-001 QSW0888-002
MONITOR ASSEMBLY <M5>
!
REF.
MODEL
GR-SXM340U GR-AXM236UC GR-AXM240UC GR-SXM240U GR-SXM245U GR-SXM245UC GR-SXM248UC
No.
ITEM
! 500 MONITOR ASSY LY20836-005A LY20836-006A LY20836-016A LY20836-005A LY20836-021A
! 501 MONITOR COVER ASSY LY20834-004A LY20834-005A LY20834-009A LY20834-004A LY20834-007A
501A PLATE(WINDOW) LY32329-002A LY32329-001A LY32329-002A
501B STICKER(B) LY32554-003A LY32554-004A LY32554-003A
505 HINGE COVER(UPPER) LY31939-004A LY31939-003A LY31939-004A LY31939-001A
MAIN BOARD ASSEMBLY <01>
!
REF.
MODEL
GR-SXM340U GR-AXM236UC GR-AXM240UC GR-SXM240U GR-SXM245U GR-SXM245UC GR-SXM248UC
No.
ITEM
PW1 MAIN BOARD ASSY YB10356UB1-01 YB10356UI1-01 YB10356UA1-01 YB10356U01-01
IC105 IC(DIGITAL) TC7S66FU-X ——————
IC4002 IC Z4C2973-32-X ——————
IC4701 IC — MM1512XN-X ————
IC4702 IC BA7665FS ——BA7665FS
IC8001 IC MAX3221CAE ——————
Q3505 TRANSISTOR DTC144EE ——DTC144EE
Q4001 TRANSISTOR DTC144EE ——DTC144EE
Q6306 MOS FET SSM3K02F — SSM3K02F
D4001 DIODE DAN222 ——DAN222
D8001 ZENER DIODE EMZ6.8N ——————
D8002 ZENER DIODE EMZ6.8N ——————
R182 MG RESISTOR NRSA63J-105X ——————
R4013 MG RESISTOR NRSA63J-102X ——————
R4014 MG RESISTOR NRSA63J-103X ——NRSA63J-103X
R4712 MG RESISTOR NRSA63D-680X ——NRSA63D-680X
R4713 MG RESISTOR NRSA63D-680X ——NRSA63D-680X
R6306 MG RESISTOR NRS12BK-R47W — NRS12BK-R47W NRS12BK-R47W
R6307 MG RESISTOR NRSA63J-104X — NRSA63J-104X NRSA63J-104X
R8001 MG RESISTOR NRSA63J-331X ——————
R8002 MG RESISTOR NRSA63J-0R0X ——————
R8003 MG RESISTOR NRSA63J-0R0X ——————
C144 CAPACITOR — NDC31HJ-101X
C4006 CAPACITOR — NDC31HJ-100X
C4024 CAPACITOR NCF31EZ-104X ——————
C4025 CAPACITOR NCB31CK-104X ——NCB31CK-104X
C4044 CAPACITOR NCB30JK-105X ——————
C4713 E CAPACITOR NEA70JM-226X ——NEA70JM-226X
C4714 E CAPACITOR NEA70GM-107X ——NEA70GM-107X
C4715 CAPACITOR NCB31EK-103X ——NCB31EK-103X
C6307 E CAPACITOR NEA71CM-106X — NEA71CM-106X
C8001 CAPACITOR NCF31EZ-104X ——————
C8002 CAPACITOR NCF31EZ-104X ——————
C8003 CAPACITOR NCF31EZ-104X ——————
C8004 CAPACITOR NCF31EZ-104X ——————
C8005 CAPACITOR NBE20JM-106X ——————
C8006 CAPACITOR NCF31EZ-104X ——————
L501 MG RESISTOR NRSA63J-0R0X ——————
L2001 COIL NQL144K-470X NQL144K-101X NQL144K-470X
L8001 COIL NQL365K-220X ——————
J505 S JACK QND0068-001 ——QND0068-001
CN6 CONNECTOR QGA1201C2-02X — QGA1201C2-02X
Notes : Mark is same as left.
Mark — is not used.
