1-4
1.3.2 Disassembly method
1
CASETTE COVER C1 2(S1)
ASSEMBLY
2
UPPER CASE C2 2(S2), 2(L2)
3
LOWER CASE C3 9(S3), (L3a), (L3b)
ASSEMBLY *CN3a,CN3b,COVER(JACK)
(Incl. E.VF ASSEMBLY)
4
E.VF ASSEMBLY C4 3(S4)
5
TOP OPERATION C5 2(S5),(L5a),(L5b),2(L5c),
UNIT *CN5a
6
REAR UNIT C6 3(S6),(L6a),(L6b),*CN6a
7
FRONT COVER C7 2(S7a),(S7b),(L7a),(L7b),
ASSEMBLY *CN7a
(Incl. MICROPHONE /
DC LIGHT ASSEMBLY)
8
MICROPHONE (S7a)
9
DC LIGHT ASSEMBLY
2(L7c)
COVER (LIGHT)
0
MONITOR C8 2(S8a),(S8b),*CN8a
ASSEMBLY
C9 2(S9a),(S9b),(S9c)
C10 2(S0a),2(S0b),2(S0c),(L0a),(L0b),
(L0c)
C11a,b (S!),(L!a),*CN!a,CN!b
C12 2(S@a),(S@b),2(L@a)
!
FRONT FRAME C13 2(S#)
ASSEMBLY
STEP
/LOC
No.
PART
Fig.
No.
REMOVAL
*UNLOCK/RELEASE/
UNPLUG/UNCLAMP/
UNSOLDER
------------------------------------------
------------------------------------------
------------------------------------------
------------------------------------------
List of Abbreviations:
2(S1)=2 screws (S1)
4(L1a)=4 Locking Tabs
CN=Connector
Reference Notes:
<NOTE 1>
Destination of connectors
Note :
Two kinds of double-arrows in connection tables
respectively show kinds of connector/wires.
: Flat wire
: Wire
Con-
nector
Connector
CN
3
a 2 SPEAKER MAIN CN27
CN
3
b 3 E.VF (B/W) MAIN CN12
CN
5
a 12 TOP OPERATION UNIT MAIN CN18
CN
6
a 13 REAR UNIT MAIN CN28
CN
7
a 2 MIC MAIN CN8
CN
8
a 25 MONITOR ASSEMBLY MAIN CN16
CN
!
a 28 MONITOR CN7601 T. HINGE
CN
!
b 24 MONITOR CN7602 LCD MODULE
No.of
Pins
<NOTE 2, 3>
(1) The FPC assembly should be winded around the hinge
assembly by two and half turns so that the wire to be
connected to the monitor board assembly is posi-
tioned inside.
(2) The upper and lower hinge covers should be mounted
so carefully the any wire is not caught into either of the
covers.
Fig. C1
Fig. C2
1
(S )
1
1
(S )
1
2
(S )
2
(L )
2
3
(S )
2
4
2
