PLAYBACK Basic Connections
VCR/TV Connection
Please refer to your VCR and/or TV instruction manual(s) when connecting.
Red to AUDIO R
Yellow to VIDEO
White to AUDIO L
AC Power
Adapter/Charger
VCR
To DC OUT jack
DC cord
Core filter
Core filter
Connect when the
S-VIDEO cable is not used
S-VIDEO cable
(provided)
To S-VIDEO
OUT connector
To AV OUT connector
To DC IN jack
To
TV or VCR
VIDEO/AUDIO
cable (provided)
To S-VIDEO IN
connector
To VIDEO IN
connector
To AUDIO IN
connector (L/R)
Core filter
