# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION

---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------

5.6 ELECTRICAL PARTS LIST

******************************

MAIN BOARD ASSEMBLY <01>

PW YB10370F MAIN BOARD ASSY

IC1001 UPD703039F1-A36 IC

(MICRO

C ROM)

or UPD70F3040F1A36 IC

(MICRO

C ROM)

IC1002 RS5C314 IC

IC1003 25LC320X-I/ST-X IC

IC1006 MB90097PFV145 IC

(MICRO

C ROM)

IC1007 SN74AHC1G08K IC

IC1008 IC-PST3423U-X IC

IC1101 TA75W01FU IC

IC1401 UPD703040YF-M13 IC

(MICRO

C ROM)

or UPD70F3040YFM13 IC

(MICRO

C ROM)

IC1601 BD6631KV IC

IC1701 TA75W01FU IC

IC1702 TA75W393FU IC

IC1801 RPM7138 IR DETECT UNIT

IC2101 AK4550VT IC

IC2201 AK4564VQ IC

IC3001 JCY0172 IC

IC3004 SN74AHC1G04K IC

or MC74VHC1G04DF IC

IC3005 JCY0136 IC

IC3501 JCY0132 IC

IC3701 BA7665FS IC

IC3731 MM1504XN IC

IC3801 JCP8045 IC(DIGITAL)

IC3901 BU2501FV IC

IC4201 HD49334AHNP IC

IC4202 TAR5S31 IC

IC4301 JCY0160-2 IC

IC4302 R1160N151B IC

IC4303 TAR5S25 IC

IC5001 CXD3602R IC

IC5002 W194-70G-X IC

IC5003 TAR5S33 IC

IC6001 S-80842CNNB-W IC

IC6002 S-817A33ANB-W IC

IC6003 S-814A30AMC-W IC

IC6101 BD9713KV IC

IC7101 CXA3272R IC

IC7201 CXA3582R IC

IC7202 MM1385HN IC

IC8001 TMS320DSC24GZA IC

or TMX320DSC24GZA IC

IC8002 K4S643233E-SE10 IC

(MICRO

C ROM)

or K4S643233E-SE80 IC

(MICRO

C ROM)

or K4S643233E-SE70 IC

(MICRO

C ROM)

IC8003 MBV160TE90PBA01 IC

(MICRO

C ROM)

IC8005 BU2288FV IC

IC8301 ISP1181ABS IC

IC8302 S-80842CNNB-W IC

IC8501 YQ44917A CSP IC ASSY

Q1001 DTC124EE DIGI TRANSISTOR

or UN9212J DIGI TRANSISTOR

Q1002 2SC4617/QR/-X TRANSISTOR

Q1003 DTC143EE DIGI TRANSISTOR

or RN1101 DIGI TRANSISTOR

or UN921LJ DIGI TRANSISTOR

Q1004 DTC143XE DIGI TRANSISTOR

Q1006 DTA114EE DIGI TRANSISTOR

or PDTA114EE DIGI TRANSISTOR

or RN2102 DIGI TRANSISTOR

or UN9111J DIGI TRANSISTOR

Q1007 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or RN1104 DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q1401 DTA114EE DIGI TRANSISTOR

or PDTA114EE DIGI TRANSISTOR

or RN2102 DIGI TRANSISTOR

or UN9111J DIGI TRANSISTOR

Q1402 UMC3N DIGI TRANSISTOR

Q1403 UMC3N DIGI TRANSISTOR

Q1601 UMC3N DIGI TRANSISTOR

Q2101 UMX18N PAIR TRANSISTOR

Q2201 2SC4617/QR/-X TRANSISTOR

Q2401 2SC4617/QR/-X TRANSISTOR

Q2403 2SC4617/QR/-X TRANSISTOR

Q2701 HN1C01FE/G/-X PAIR TRANSISTOR

Q2702 HN1C01FE/G/-X PAIR TRANSISTOR

Q3001 2SC4617/RS/-X TRANSISTOR

Q3002 2SC4617/RS/-X TRANSISTOR

Q3701 UMT1N PAIR TRANSISTOR

Q3702 UMZ1N PAIR TRANSISTOR

Q3704 2SA1774/RS/-X TRANSISTOR

Q3705 UMT1N PAIR TRANSISTOR

Q3731 2SC4617/RS/-X TRANSISTOR

Q3732 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or RN1104 DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q3733 UMZ1N PAIR TRANSISTOR

Q3734 2SC4617/RS/-X TRANSISTOR

Q3735 UMZ1N PAIR TRANSISTOR

Q6001 MCH3308 MOS FET

Q6002 2SK3019 MOS FET

or 2SK1830 MOS FET

Q6003 MCH6613 MOS FET

Q6004 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or RN1104 DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q6101 SSM5G01TU MOS FET

Q6102 SSM5G01TU MOS FET

Q6103 SSM5G01TU MOS FET

Q6104 SSM5G01TU MOS FET

Q6105 SSM5G01TU MOS FET

Q6106 NDS352AP MOS FET

Q6107 2SC4617/RS/-X TRANSISTOR

Q6108 UMZ1N PAIR TRANSISTOR

Q6109 HN1C01FU/G/-X PAIR TRANSISTOR

or PUMX1 PAIR TRANSISTOR

or UMX1N PAIR TRANSISTOR

Q6110 2SA1577/RS/-X TRANSISTOR

Q7101 2SA1577/QR/-X TRANSISTOR

Q7102 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or RN1104 DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR

Q7203 DTC144EE DIGI TRANSISTOR

or PDTC144EE DIGI TRANSISTOR

or RN1104 DIGI TRANSISTOR

or UN9213J DIGI TRANSISTOR
