5-21
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
******************************
CCD BOARD ASSEMBLY <05>
PW YB20926A-01 CCD BOARD ASSY
Q5201 2SC3931/CD/-X TRANSISTOR
Q5202 2SC4081/RS/-X TRANSISTOR
Q5203 2SC3931/CD/-X TRANSISTOR
R5201 NRSA63J-472X MG RESISTOR 4.7kØ,1/16W
R5202 NRSA63J-102X MG RESISTOR 1kØ,1/16W
R5203 NRSA63J-103X MG RESISTOR 10kØ,1/16W
R5204 NRSA63J-123X MG RESISTOR 12kØ,1/16W
R5205 NRSA63J-103X MG RESISTOR 10kØ,1/16W
C5202 NBP41DM-106X T CAPACITOR 10
µ F,20V
C5203 NCF31EZ-104X CAPACITOR 0.1
µ F,25V
C5204 NBE21AM-106X T CAPACITOR 10
µ F,10V
C5205 NCB31CK-104X CAPACITOR 0.1 µ F,16V
C5206 NCB21EK-104X CAPACITOR 0.1 µ F,25V
C5207 NCB31HK-222X CAPACITOR 0.0022 µ F,50V
C5211 NCB31CK-104X CAPACITOR 0.1 µ F,16V
OT1 LY30029-0V8A SPACER(A)
******************************
EJECT BOARD ASSEMBLY <06>
PW2 YB10372A2 EJECT BOARD ASSY
S1 NSW0095-001X DETECT SWITCH,EJECT SW
WR1 WJM0286-001A E-SI C WIRE C-F,EJECT-MAIN CN108
******************************
VF BL BOARD ASSEMBLY <07>
PW2 YB20933A2 VF BL BOARD ASSY
Q7001 UMD3N DIGI TRANSISTOR
Q7002 PUMX1 PAIR TRANSISTOR
D7001 NSCW100A0/ST/-X LE DIODE
R7001 NRSA63J-332X MG RESISTOR 3.3kØ,1/16W
R7002 NRSA63J-561X MG RESISTOR 560Ø,1/16W
R7003 NRSA63J-470X MG RESISTOR 47Ø,1/16W
R7005 NRSA63J-333X MG RESISTOR 33kØ,1/16W
C7001 NCB31CK-104X CAPACITOR 0.1 µ F,16V
C7002 NCB31CK-104X CAPACITOR 0.1 µ F,16V
C7003 NCB31CK-104X CAPACITOR 0.1 µ F,16V
CN7001 QGF0517F2-20X FPC CONNECTOR
CN7002 QGF0517F1-16X FPC CONNECTOR
(Sanwa)-M2D7S8
