5-19
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
CN107 QGB0406L1-50X CONNECTOR
CN108 QGA1001F1-02X CONNECTOR
CN109 QGF0520F2-13X FFC/FPC CONNECTOR
CN110 QGB0404M1-80X CONNECTOR
CN111 QGF0517F2-20X FPC CONNECTOR
CN112 QGF0517F1-08X FPC CONNECTOR
CN113 QGF0306F1-39X FPC CONNECTOR
CN114 QGB0512L4-40X CONNECTOR
CN115 QGA1001F1-04X CONNECTOR
! F6101 NMFZ007-2R0X-K FUSE T2.0A,50V
! F6102 NMFZ007-2R0X-K FUSE T2.0A,50V
! F6103 NMFZ007-1R0X-K FUSE T1.0A,50V
OT1 LY30029-0W6A SPACER(A)
OT2 LY30029-0V3A SPACER(A)
OT3 LY30029-0V7A SPACER(A)
OT4 LY30029-0W3A SPACER(A)
OT5 LY30029-0X7A SPACER(A)
OT6 LY30029-0W9A SPACER(A)
OT7 LY30029-0X6A SPACER(A)
! OT8 LY43187-001A LABEL(FUSE)
OT9 LY30029-0X9A SPACER(A)
SD1 LY32271-001B SHIELD CASE(PR)
SD2 LY43856-001B SHIELD(CCD2)
******************************
OP MDA BOARD ASSEMBLY <02>
PW YB10371A OP MDA BOARD ASSY
IC4802 TA75W01FU IC
IC4803 TA75W01FU IC
IC4804 NJM3414AV IC
IC4805 MM6564XFBE IC
IC4806 TC7S08FU IC(DIGITAL)
IC4851 UPD16879GS IC
Q1151 RPM-22PB PHOTO TRANSISTOR
Q2001 DTC143XE DIGI TRANSISTOR
Q2901 2SB1121/TU/-X TRANSISTOR
or 2SB1121/ST/-X TRANSISTOR
Q2902 2SC5658 TRANSISTOR
Q4801 2SC4655/BC/-X TRANSISTOR
Q4802 2SC5658 TRANSISTOR
Q4803 DTC144EE DIGI TRANSISTOR
Q4804 DTA144EE DIGI TRANSISTOR
Q4805 2SC4617/RS/-X TRANSISTOR
Q4806 2SA1774/QR/-X TRANSISTOR
Q4851 2SC5658 TRANSISTOR
D2001 CL-221HR-C-X LE DIODE
D2901 EMZ6.8N ZENER DIODE
D2902 EMZ6.8N ZENER DIODE
D2903 EMZ6.8N ZENER DIODE
R1151 NRSA6AJ-302W MG RESISTOR 3kØ,1/16W
R2001 NRSA6AJ-471W MG RESISTOR 470Ø,1/16W
R2903 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R2905 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R2906 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R2907 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W
R2908 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W
R2919 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R2920 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R4804 NRSA6AJ-564W MG RESISTOR 560kØ,1/16W
R4805 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R4806 NRSA6AJ-683W MG RESISTOR 68kØ,1/16W
R4807 NRSA6AJ-683W MG RESISTOR 68kØ,1/16W
R4808 NRSA6AJ-243W MG RESISTOR 24kØ,1/16W
R4809 NRSA6AJ-331W MG RESISTOR 330Ø,1/16W
R4810 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R4811 NRSA6AJ-564W MG RESISTOR 560kØ,1/16W
R4812 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W
R4814 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R4815 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W
R4816 NRSA6AJ-105W MG RESISTOR 1MØ,1/16W
R4817 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W
R4818 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R4819 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R4820 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W
R4821 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W
R4822 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W
R4823 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R4824 NRSA6AJ-472W MG RESISTOR 4.7kØ,1/16W
R4825 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W
R4826 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W
R4828 NRSA6AJ-183W MG RESISTOR 18kØ,1/16W
R4829 NRSA6AJ-122W MG RESISTOR 1.2kØ,1/16W
R4830 NRSA6AJ-222W MG RESISTOR 2.2kØ,1/16W
R4831 NRSA6AJ-473W MG RESISTOR 47kØ,1/16W
R4832 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W
R4833 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W
R4834 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W
R4836 NRSA6AJ-561W MG RESISTOR 560Ø,1/16W
R4841 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R4842 NRSA6AJ-103W MG RESISTOR 10kØ,1/16W
R4848 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W
R4856 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
R4857 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
R4858 NRSA6AJ-333W MG RESISTOR 33kØ,1/16W
R4862 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
R4863 NRSA63J-6R8X MG RESISTOR 6.8Ø,1/16W
R4864 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R4865 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R4866 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R4867 NRSA6AJ-102W MG RESISTOR 1kØ,1/16W
R4868 NRSA6AJ-101W MG RESISTOR 100Ø,1/16W
R4870 NRSA6AJ-271W MG RESISTOR 270Ø,1/16W
R9901 NRSA6AJ-104W MG RESISTOR 100kØ,1/16W
R9902 NRSA6AJ-153W MG RESISTOR 15kØ,1/16W
R9903 NRSA6AJ-183W MG RESISTOR 18kØ,1/16W
R9904 NRSA6AJ-273W MG RESISTOR 27kØ,1/16W
C1151 NBZ0015-106X T CAPACITOR 10 µ F,6.3V
C1152 NCB21HK-683X-R CAPACITOR 0.068 µ F,50V
C2901 NCBA1CK-103W CAPACITOR 0.01 µ F,16V
C2904 NCBA1CK-103W CAPACITOR 0.01 µ F,16V
C4803 NBZ0015-106X T CAPACITOR 10 µ F,6.3V
C4804 NCFA1AZ-104W CAPACITOR 0.1 µ F,10V
C4805 NCFA1AZ-104W CAPACITOR 0.1 µ F,10V
C4806 NCFA1AZ-104W CAPACITOR 0.1 µ F,10V
C4808 NCB30JK-105X CAPACITOR 1 µ F,6.3V
C4809 NCFA1AZ-104W CAPACITOR 0.1 µ F,10V
C4810 NCFA1HZ-103W CAPACITOR 0.01 µ F,50V
C4811 NCFA1HZ-103W CAPACITOR 0.01 µ F,50V
C4812 NCFA1AZ-104W CAPACITOR 0.1 µ F,10V
C4813 NCFA1AZ-104W CAPACITOR 0.1 µ F,10V
C4814 NCFA1AZ-104W CAPACITOR 0.1 µ F,10V
C4815 NCB31HK-152X CAPACITOR 0.0015 µ F,50V
