CONTENTS
Features 0: 2. seeds ota cia arty Sense aes Sat dosh SAT ade beeen 34. Index search function «if oc cad oe nee es ned 53
PreGauitions: 6: oii /ocdeat bia ck 2k heptane hae deen 35 Realtime tape counter functions ............0.008 54
Controls, indicators and connectors ............... 36 Counter memory function/lap time indication ........ 55
Connecthons? of ons ee Se soe plone Ore een Ba 39 Remaining tape time indicator ..............-00- 55
For a better understanding of S-VHS and VHS........ 41 Intro search function... 2... ee eee eee 55
Video channel setting .........-0 0.00 e eee e eee 42 Nextfunctionmemory ..... 56... eee eee eee 56
ClOck Setting: ssivesials- dak ins koe wens Mes Sg Be ada 42 Audio dubbing. ......-. 6-6... ee eee eee eee eee 56
Operating the builtin tuner ...........0....0000. 43 Automatic timer recording... 2... 6.6... e eee eee 57
Information on the HR-S5O00EG’s audio system ...... 45 WPSrecording ....... 20... 0. eee eee eee 59
Loading and unloading a cassette................. 4g _iInsertediting.... 6.66... cee eee eee eee eee 60
Playing back a video cassette... .......2. 0.00000 49 Recording from an external source.............04- 61
Special-effects playback... ......0.0..-0 000 eae 50 in case of difficulty... 6... ee ee eee eee 61
Basic operation for recording TV programmes ........ 51 Headcleaning ©... 2... 6 eee eee eee eee 62
Other recording possibilities ..............-0005. 52 Specifications ... 11... eee eee eee eee 63
SAFETY PRECAUTION————
The rating plate and the safety caution are on the rear of the unit.
WARNING — DANGEROUS VOLTAGE INSIDE
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE.
IMPORTANT (in the United Kingdom)
Mains Supply (240 V~, 50 Hz only)
IMPORTANT
Do not make any connection to the Larger Terminal coded
E or Green. The wires in the mains lead are coloured in
accordance with following code:
Blue to N (Neutral) or Black
Brown to L (Live) or Red
lf these colours do not correspond with the terminal
identifications of your plug, connect as follows:
Blue wire to terminal coded N (Neutral) or coloured Black.
Brown wire to terminal coded L (Live) or coloured Red.
if in doubt — consult a competent electrician.
CAUTION
@When you are not using the HR-SSOOOEG for a long period
of time, it is recommended that you disconnect the power
cord from the AC outlet.
®Dangerous voltage inside. Refer internal servicing to quali-
fied service personnel. To prevent electric shock or fire
hazard, remove the power cord from the AC outlet prior to
connecting or disconnecting any signal lead or aerial.
i] Cassettes marked “S-VHS” and “VHS” can be
=—
VHS used with this video cassette recorder. However,
= S-VHS recordings are possible only with cas-
625 — settes marked “S-VHS”.
FOR YOUR SAFETY (in Australia)
Install any external aerial to AS 1417.1
Omkoppiaren BETRIEB pa denna apparat ar
sekundart kopplad och skijer inte apparaten fran
natet i lage BETRIEB AUS.
The BETRIEB button does not completely shut off
mains power from the unit, but switches operating current
on and off.
BEMAERK: | stilling AUS er apparatet stadig forbundet
med lysnettet Hvis det dnskes fuldstaendig afbrudt skai
netledningen traekkes ud.
This unit is produced to comply with Directive 82/499/
EEC, CISPR Pub. 13 and Pub. 14 and Standard IEC 65.
Video tapes recorded with this video recorder in the LP
{Long Play) mode cannot be played back on a single-speed
video recorder.
COPYRIGHT © 1988 VICTOR COMPANY OF JAPAN, LTD.
Printed in Japan

JVC HR-S5000 Specifications

Power

power requirement	220 V, 50/60 Hz
power consumption	44 W

Operating Environment

operating temperature	5°C to 40°C
storage temperature	-20°C to 60°C
operating humidity	25% to 80%
storage humidity	35% to 80%

Video Specifications

video signal system	PAL colour and separated Y/C signals, 625 lines
horizontal resolution (S-VHS)	More than 400 lines
horizontal resolution (VHS)	250 lines

Audio Specifications

frequency response	20 Hz — 20, 000 Hz
dynamic range	More than 90 dB
wow and flutter	Less than 0.005 % WRMS

TV Tuner/RF Section

channel storage capacity	48 channels
aerial input VHF frequency range	47 — 89 MHz, 104 — 300 MHz, 302 — 470 MHz
aerial input UHF frequency range	470 — 862 MHz

Weight and Dimensions

width	435 mm
height	105 mm
depth	380 mm
weight	7.4 kg
