67
ENGLISH
Specifications
AMPLIFIER
Maximum Power Output Front/Rear 50 W per channel
Continuous Power Output
(RMS)
Front/Rear 20 W per channel into 4 , 40 Hz to 20 000
Hz at no more than 0.8% total harmonic
distortion
Load Impedance 4 (4 to 8 allowance)
Equalizer Control Range Frequencies Low: 60 Hz, 80 Hz, 100 Hz, 200 Hz
Mid: 500 Hz, 1 kHz, 1.5 kHz, 2.5 kHz
High: 10 kHz, 12.5 kHz, 15 kHz, 17.5 kHz
Level ±12 dB
Signal-to-Noise Ratio 70 dB
Audio Output Level
FRONT OUT, REAR OUT, SUBWOOFER
OUT
Line-Out Level/Impedance 5 V/20 kΩ load (full scale)
Output Impedance 1 kΩ
Color System PAL
Video Output (composite) 1 Vp-p/75 Ω
Other Terminals Input LINE IN, VIDEO IN, CAMERA IN*
1
, USB input,
MIC IN*
1
, Aerial input
Output 2nd AUDIO OUT*
1
Others Expansion port*
2
, OE REMOTE
FM/AM TUNER
Frequency Range FM 87.5 MHz to 108.0 MHz
AM (MW) 522 kHz to 1 620 kHz
(LW) 144 kHz to 279 kHz
FM Tuner Usable Sensitivity 9.3 dBf (0.8 μV/75 Ω)
50 dB Quieting Sensitivity 16.3 dBf (1.8 μV/75 Ω)
Alternate Channel Selectivity
(400 kHz)
65 dB
Frequency Response 40 Hz to 15 000 Hz
Stereo Separation 40 dB
MW Tuner Sensitivity/Selectivity 20 μV/40 dB
LW Tuner Sensitivity 50 μV
*
1
Only for KW-AVX830.
*
2
Only for KW-AVX730.
EN_KW-AVX830[E].indb 67EN_KW-AVX830[E].indb 67 10.1.19 3:10:11 PM10.1.19 3:10:11 PM
