(No.YA408)3-15
D-AMP P.W. BOARD ASS'Y (SFL-6222A-U2)
SW P.W. BOARD ASS'Y (SFL-7206A-U2)
L3502 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L3503 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L3504 NQL79GM-4R7X COIL 4.7uH M
L3506 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L3507 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L3508 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L3509 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
CN001 QGF0508C2-50W CONNECTOR FFC/FPC (1-50)
CN002 QGF0508C2-40W CONNECTOR FFC/FPC (1-40)
J401 QNZ0463-001 21P CONNECTOR EXT-1
J402 QNZ0463-001 21P CONNECTOR EXT-2
J403 QNZ0726-001 AV JACK EXT-3
J405 QNN0649-001 PIN JACK AUDIO OUT
J406 QNN0650-001 PIN JACK EXT-4
J410 QNZ0561-001 D CONNECTOR PC IN
K3501 NQR0389-003X FERRITE BEADS
K3502 NQR0389-003X FERRITE BEADS
LC3501 NQR0431-001X EMI FILTER 0.22uF 50V Z
TU3002 QAU0428-003 TUNER
UD3001 QAU0429-001 RF SPLITTER
X3501 QAX0773-001Z CRYSTAL 18.432000MHz
Ref No. Part No. Part Name Description Local
IC6201 PQ20WZ11-X IC
IC6501 RC4558D-X IC
IC6621 LM393DR-X IC
IC6661 TDA8928ST/N1 IC
Q6661 UN2112-X DIGI TRANSISTOR
Q6662 2SC3928A/QR/-X TRANSISTOR
Q6663 UN2212-X DIGI TRANSISTOR
D6201 1SS355W-X DIODE
D6501 UDZW6.2B-X Z DIODE
D6663 UDZW3.3B-X Z DIODE
D6664 1SS355W-X DIODE
D6671 UDZW20B-X Z DIODE
D6672 UDZW20B-X Z DIODE
D6673 UDZW20B-X Z DIODE
D6674 UDZW20B-X Z DIODE
C6201 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6202 NEHL1EM-336X E CAPACITOR 33uF 25V M
C6203 NEHL1EM-336X E CAPACITOR 33uF 25V M
C6204 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C6205 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6501 NENA1CM-475X BP E CAPACITOR 4.7uF 16V M
C6502 NENA1CM-475X BP E CAPACITOR 4.7uF 16V M
C6503 NDC31HJ-100X C CAPACITOR 10pF 50V J
C6504 NDC31HJ-100X C CAPACITOR 10pF 50V J
C6505 NEHL1CM-476X E CAPACITOR 47uF 16V M
C6506 NEHL1CM-476X E CAPACITOR 47uF 16V M
C6507 NEHL1HM-105X E CAPACITOR 1uF 50V M
C6508 NEHL1HM-105X E CAPACITOR 1uF 50V M
C6601 NDC31HJ-101X C CAPACITOR 100pF 50V J
C6602 NDC31HJ-101X C CAPACITOR 100pF 50V J
C6621 NCB31HK-332X C CAPACITOR 3300pF 50V K
C6622 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6623 NEHL1EM-226X E CAPACITOR 22uF 25V M
C6624 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6625 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6626 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6627 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6628 NEHL1EM-226X E CAPACITOR 22uF 25V M
C6629 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6630 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6631 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6632 NCB31HK-332X C CAPACITOR 3300pF 50V K
C6661 NCB11EK-105X C CAPACITOR 1uF 25V K
C6662 NCB11EK-105X C CAPACITOR 1uF 25V K
C6663 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6664 QETN1HM-226Z E CAPACITOR 22uF 50V M
C6665 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6666 QETN1HM-226Z E CAPACITOR 22uF 50V M
C6667 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6668 NCB31HK-561X C CAPACITOR 560pF 50V K
C6669 QFV21HJ-224Z MF CAPACITOR 0.22uF 50V J
C6670 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C6671 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C6672 QETN1EM-477Z E CAPACITOR 470uF 25V M
C6673 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6674 QETN1EM-477Z E CAPACITOR 470uF 25V M
C6675 NCB31HK-104X C CAPACITOR 0.1uF 50V K
Ref No. Part No. Part Name Description Local
C6676 NCB31HK-561X C CAPACITOR 560pF 50V K
C6677 NCB31HK-561X C CAPACITOR 560pF 50V K
C6678 QFV21HJ-224Z MF CAPACITOR 0.22uF 50V J
C6679 QFVF1HJ-474Z MF CAPACITOR 0.47uF 50V J
C6680 NCB31HK-153X C CAPACITOR 0.015uF 50V K
C6681 NCB31HK-561X C CAPACITOR 560pF 50V K
C6682 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6683 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6684 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6685 QETN1EM-477Z E CAPACITOR 470uF 25V M
C6686 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6687 QETN1EM-477Z E CAPACITOR 470uF 25V M
R6201 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R6202 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R6203 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R6204 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R6205 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R6501 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R6502 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6503 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R6504 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R6505 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6506 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R6507 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R6601 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6602 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R6603 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R6605 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6606 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R6607 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R6621 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R6622 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6623 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R6624 QRJ146J-102X UNF C RESISTOR 1k
Ω
1/4W J
R6625 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6626 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R6627 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R6629 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R6630 NRSA63J-152X MG RESISTOR 1.5k
Ω
1/16W J
R6631 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6632 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R6633 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
R6634 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6661 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6662 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6663 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R6664 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R6665 NRSA63J-393X MG RESISTOR 39k
Ω
1/16W J
R6666 QRK126J-5R6X UNF C RESISTOR 5.6
Ω
1/2W J
R6667 QRK126J-220X UNF C RESISTOR 22
Ω
1/2W J
R6668 QRK126J-5R6X UNF C RESISTOR 5.6
Ω
1/2W J
R6669 QRK126J-220X UNF C RESISTOR 22
Ω
1/2W J
R6670 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R6671 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6673 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R6674 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R6675 NRSA63J-273X MG RESISTOR 27k
Ω
1/16W J
R6676 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6677 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R6680 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R6691 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
L6661 NQLC8CM-560X COIL 56uH M
L6662 NQLC8CM-560X COIL 56uH M
K6601 NQR0499-002X FERRITE BEADS
K6602 NQR0499-002X FERRITE BEADS
K6661 NQR0499-002X FERRITE BEADS
K6662 NQR0499-002X FERRITE BEADS
K6663 NQR0499-002X FERRITE BEADS
K6664 NQR0499-002X FERRITE BEADS
TH6401 NAD0035-471X P THERMISTOR 470
Ω
Ref No. Part No. Part Name Description Local
D7011 UDZW6.2B-X Z DIODE
C7011 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7012 NCB31HK-104X C CAPACITOR 0.1uF 50V K
R7011 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7012 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7013 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7014 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
Ref No. Part No. Part Name Description Local
