3-42(No.YA408)
PRINTED WIRING BOARD PARTS LIST [LT-37DR7BJ, LT-37DR7SJ]
ANALOG P.W. BOARD ASS'Y (SFL-1247A-U2)
REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.
D-AMP P.W. BOARD ASS'Y (SFL-6222A-U2)
REFER TO PARTS LIST IN PAGE 3-15 FOR THIS P.W. BOARD.
SW P.W. BOARD ASS'Y (SFL-7209A-U2)
LED P.W. BOARD ASS'Y (SFL-8904A-U2)
REFER TO PARTS LIST IN PAGE 3-16 FOR THIS P.W. BOARD.
POWER P.W. BOARD ASS'Y (SFL-9047A-U2)
Ref No. Part No. Part Name Description Local
D7011 UDZW6.2B-X Z DIODE
D7011 MA8062/M/-X Z DIODE
C7011 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7011 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C7012 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C7012 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R7011 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7012 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7013 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7014 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7015 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7016 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7017 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7701 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R7702 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R7703 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R7704 NRSA63J-822X MG RESISTOR 8.2k
Ω
1/16W J
R7707 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7708 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7710 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R7711 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L7001 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
J7001 QNS0051-001 3.5 JACK HEADPHONE
K7001 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
S7701 QSW0619-003Z PUSH SWITCH CH-
S7702 QSW0619-003Z PUSH SWITCH CH+
S7703 QSW0619-003Z PUSH SWITCH MENU/OK
S7704 QSW0619-003Z PUSH SWITCH TV/AV
S7705 QSW0619-003Z PUSH SWITCH VOL+
S7706 QSW0619-003Z PUSH SWITCH VOL-
S7707 QSW0619-003Z PUSH SWITCH POWER
Ref No. Part No. Part Name Description Local
IC9201 MIP2C20MSSCF IC
IC9501 F9222L-F219 IC
IC9502 FA5500AN-W IC
IC9551 UTCTL431-T IC
Q9001 2SC3928A/QR/-X TRANSISTOR
Q9002 2SC3928A/QR/-X TRANSISTOR
Q9501 2SK3522-01-F1 POWER MOS FET
Q9502 2SC3928A/QR/-X TRANSISTOR
Q9503 2SC3928A/QR/-X TRANSISTOR
Q9504 UN2213-X DIGI TRANSISTOR
Q9505 UN2212-X DIGI TRANSISTOR
Q9506 UN2212-X DIGI TRANSISTOR
Q9507 2SB1188/QR/-W TRANSISTOR
Q9508 UN2212-X DIGI TRANSISTOR
Q9531 2SC3928A/QR/-X TRANSISTOR
Q9532 2SB1188/QR/-W TRANSISTOR
Q9533 UN2212-X DIGI TRANSISTOR
Q9534 UN2213-X DIGI TRANSISTOR
Q9535 UN2213-X DIGI TRANSISTOR
Q9536 2SA1530A/QR/-X TRANSISTOR
Q9537 2SA1530A/QR/-X TRANSISTOR
Q9551 UN2212-X DIGI TRANSISTOR
Q9552 UN2212-X DIGI TRANSISTOR
Q9553 2SC3928A/QR/-X TRANSISTOR
D9001 TS25P05G-C2 BRIDGE DIODE
D9002 1SS355W-X DIODE
D9003 1SS355W-X DIODE
D9203 EG01C-T2 SI DIODE
D9204 RF101L2S-X SI DIODE
D9205 UTCTL431-T IC
D9206 EC21QS10-X SB DIODE
D9208 RF101L2S-X SI DIODE
D9212 EM1A-LFF4 SI DIODE
D9213 EM1A-LFF4 SI DIODE
D9214 EM1A-LFF4 SI DIODE
D9215 MA8330/M/-X Z DIODE
D9216 MA8330/M/-X Z DIODE
D9501 YG972S6R SI DIODE
D9502 RF101L2S-X SI DIODE
D9503 1SS355W-X DIODE
D9504 1SS355W-X DIODE
D9505 RF101L2S-X SI DIODE
D9506 1SS355W-X DIODE
D9507 MA8100/M/-X Z DIODE
D9508 1SS355W-X DIODE
D9531 D1FS4-X SB DIODE
D9532 1SS355W-X DIODE
D9533 UDZS5.6B-X Z DIODE 1.5k
Ω
1/10W J
D9534 SD883-04-X SB DIODE
D9535 PTZ27B-X Z DIODE
D9536 PTZ27B-X Z DIODE
D9537 1SS355-X SI DIODE
D9550 FCH20A10 SB DIODE
D9551 FCH20A10 SB DIODE
D9552 FCH20A10 SB DIODE
D9553 FCH20A10 SB DIODE
D9555 RU3YX-LFC4 SI DIODE
D9556 RU3YX-LFC4 SI DIODE
D9557 RF101L2S-X SI DIODE
D9558 RF101L2S-X SI DIODE
D9559 MA3100/H/-X Z DIODE
D9560 MA3100/H/-X Z DIODE
D9562 1SS355W-X DIODE
D9563 MA3100/H/-X Z DIODE
C9001 QFZ9072-105 MM CAPACITOR 1uF AC250V K
C9002 QFZ9072-105 MM CAPACITOR 1uF AC250V K
C9003 QCZ9071-102 C CAPACITOR 1000pF AC400V M
C9004 QCZ9071-102 C CAPACITOR 1000pF AC400V M
C9006 QCZ9078-222 C CAPACITOR 2200pF AC250V M
C9007 QCZ9078-222 C CAPACITOR 2200pF AC250V M
C9008 QCZ9078-222 C CAPACITOR 2200pF AC250V M
C9009 QCZ9078-222 C CAPACITOR 2200pF AC250V M
C9204 QEZ0709-106 E CAPACITOR 10uF 450V M
C9205 QFP32JK-222 PP CAPACITOR 2200pF 630V K
C9206 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9207 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9208 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9209 QCZ9071-102 C CAPACITOR 1000pF AC400V M
C9210 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9211 QECR1VM-477Z E CAPACITOR 470uF 35V M
C9212 QEHR1AM-337Z E CAPACITOR 330uF 10V M
C9219 QEHR1VM-107Z E CAPACITOR 100uF 35V M
C9501 QEZ0650-227 E CAPACITOR 220uF 450V M
C9502 QCZ0340-331 C CAPACITOR 330pF 2kV K
C9503 QFZ0222-105 MM CAPACITOR 1uF 450V K
C9504 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9505 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9506 NCB21EK-474X C CAPACITOR 0.47uF 25V K
C9507 NDC31HJ-102X C CAPACITOR 1000pF 50V J
C9508 QEHR1VM-476Z E CAPACITOR 47uF 35V M
C9509 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9510 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9511 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C9531 NCB31HK-331X C CAPACITOR 330pF 50V K
C9532 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C9533 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C9534 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9535 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9536 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9537 NCB31HK-331X C CAPACITOR 330pF 50V K
C9538 NCB11AK-106X C CAPACITOR 10uF 10V K
C9539 QEHR1HM-226Z E CAPACITOR 22uF 50V M
C9540 QFZ0230-393 MPP CAPACITOR 0.039uF
C9541 NCB31HK-472X C CAPACITOR 4700pF 50V K
C9542 QCZ9071-102 C CAPACITOR 1000pF AC400V M
C9551 QECQ1VM-128 E CAPACITOR 1200uF 35V M
C9552 QECQ1VM-128 E CAPACITOR 1200uF 35V M
Ref No. Part No. Part Name Description Local
To Next Page
