JVC LT-26DR7BJ Service Manual

3-44(No.YA408)
DIGITAL P.W. BOARD ASS'Y (SFL0D266A-U2)
C9606 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9607 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9608 NCB31HK-332X C CAPACITOR 3300pF 50V K
C9610 NEHM1HM-105X E CAPACITOR 1uF 50V M
C9651 NCJ41HK-335X-U C CAPACITOR 3.3uF 50V K
C9652 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9654 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9655 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9656 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9657 NDC31HJ-101X C CAPACITOR 100pF 50V J
C9658 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9660 NBZ0010-396X SP E CAPACITOR 39uF 16V M
C9681 NEHM1HM-105X E CAPACITOR 1uF 50V M
C9682 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9683 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9684 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9701 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9703 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9704 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9705 NCJ41CK-226X-U C CAPACITOR 22mF 16V K
C9707 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9751 NEHM1CM-106X E CAPACITOR 10uF 16V M
C9752 NCB31AK-334X C CAPACITOR 0.33uF 10V K
C9753 NCB31AK-105X C CAPACITOR 1uF 10V K
C9754 NDC31HJ-471X C CAPACITOR 470pF 50V J
C9802 NCJ41HK-335X-U C CAPACITOR 3.3uF 50V K
C9803 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9804 NCJ41CM-226X-M C CAPACITOR 22uF 16V M
C9805 NCJ41CM-226X-M C CAPACITOR 22uF 16V M
C9806 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9808 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9809 NCB31HK-332X C CAPACITOR 3300pF 50V K
C9851 NEHM1EM-336X E CAPACITOR 33uF 25V M
C9852 NEHM1EM-336X E CAPACITOR 33uF 25V M
C9853 NEHM1EM-336X E CAPACITOR 33uF 25V M
C9854 NEHM1EM-336X E CAPACITOR 33uF 25V M
C9901 NCJ41HK-335X-U C CAPACITOR 3.3uF 50V K
C9902 NCJ41HK-335X-U C CAPACITOR 3.3uF 50V K
C9903 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9905 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9906 NCJ41EK-106X-U C CAPACITOR 10mF 25V K
C9909 NCB31EK-273X C CAPACITOR 0.027uF 25V K
R9601 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9602 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9603 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R9604 NRVA02D-473X CMF RESISTOR 47k Ω 1/10W D
R9605 NRSA63D-104X MG RESISTOR 100k Ω 1/16W D
R9606 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R9607 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R9608 NRSA63J-182X MG RESISTOR 1.8k Ω 1/16W J
R9609 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R9610 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R9651 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9652 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9653 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9654 NRSA63J-824X MG RESISTOR 820k Ω 1/16W J
R9655 NRSA63D-104X MG RESISTOR 100k Ω 1/16W D
R9656 NRSA63D-103X MG RESISTOR 10k
Ω 1/16W D
R9657 NRSA63J-682X MG RESISTOR 6.8k Ω 1/16W J
R9658 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R9659 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R9660 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R9661 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R9668 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R9681 NRS12BJ-332W MG RESISTOR 3.3k
Ω 1/2W J
R9682 NRSA63D-472X MG RESISTOR 4.7k
Ω 1/16W D
R9683 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R9684 NRSA63D-472X MG RESISTOR 4.7k
Ω 1/16W D
R9685 NRSA63D-273X MG RESISTOR 27k
Ω 1/16W D
R9686 NRSA63D-472X MG RESISTOR 4.7k
Ω 1/16W D
R9703 NRSA02J-680X MG RESISTOR 68
Ω 1/10W J
R9704 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9707 NRSA63D-203X MG RESISTOR 20k Ω 1/16W D
R9708 NRSA63D-124X MG RESISTOR 120k
Ω 1/16W D
R9710 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R9711 NRS181J-181X MG RESISTOR 180
Ω 1/8W J
R9712 NRS181J-181X MG RESISTOR 180
Ω 1/8W J
R9801 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9802 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R9803 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R9804 NRSA63D-473X MG RESISTOR 47k Ω 1/16W D
R9805 NRSA63D-104X MG RESISTOR 100k
Ω 1/16W D
R9806 NRSA63D-103X MG RESISTOR 10k Ω 1/16W D
R9807 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R9808 NRSA63J-182X MG RESISTOR 1.8k
Ω 1/16W J
R9809 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R9810 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
R9852 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
R9904 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
 Ref No. Part No. Part Name Description Local
R9905 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R9907 NRSA63D-104X MG RESISTOR 100k Ω 1/16W D
R9908 NRSA63D-103X MG RESISTOR 10k
Ω 1/16W D
R9910 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R9911 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R9912 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R9919 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R9924 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R9929 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
L9602 NQLC8CM-150X COIL 15uH M
L9652 NQLC8CM-150X COIL 15uH M
L9653 NQR0562-003X CHOKE COIL
L9701 NQLC8CM-150X COIL 15uH M
L9802 NQLC8CM-150X COIL 15uH M
L9901 NQLC8CM-150X COIL 15uH M
 Ref No. Part No. Part Name Description Local
IC6001 JCC5060 IC
IC6002 SN74LVC1G08V-X IC
IC6101 EDD1232AAFA-6B IC
IC6102 SC2595STRT-X IC
IC6250 UPC5702GS-027-X IC
IC6251 R1170H331B-X IC
IC6301 SN74AHCT1G08V-X IC
IC6302 SN74AHCT1G08V-X IC
IC6401 ISL98001CQZ-140 IC
IC6402 R1170H331B-X IC
IC6502 THC63LVDM83R-W IC
IC6724 S-80928CLNB-G-W IC
IC7033 CD74HC4094PW-X IC
IC7036 ADC081S021CIS-X IC
IC7038 SN74LVC2G17KE-X IC
IC7201 39VF800A7IEKD71 IC(MICRO C ROM)
IC7203 M12L16161A-7TG IC
IC7204 S-80928CLNB-G-W IC
IC7205 SN74LV00APW-X IC
IC7301 SDA6000-B12 IC
IC7302 MR27T1602F321TN IC
IC7303 K4S641632K-UC75 IC
IC7304 CD74HC4053PW-X IC
IC7305 MM1689CH-X IC
IC7306 S-80928CLNB-G-W IC
IC7502 SN74LVC2G06K-X IC
IC7602 ATF32-37DR7BJ IC (SERVICE)
IC7606 MM1671XN-X IC
IC9001 MP2263DN-C053-X IC
IC9101 MM1662FT-X IC
IC9201 MP2263DN-C053-X IC
IC9301 MM1701CH-X IC
Q6202 2SA1530A/QR/-X TRANSISTOR
Q6203 2SA1022/BC/-X TRANSISTOR
Q6204 2SA1022/BC/-X TRANSISTOR
Q6205 2SA1022/BC/-X TRANSISTOR
Q6206 2SA1022/BC/-X TRANSISTOR
Q6211 2SC3837K/NP/-X TRANSISTOR
Q6212 2SC3837K/NP/-X TRANSISTOR
Q6213 2SC3837K/NP/-X TRANSISTOR
Q6214 2SC3837K/NP/-X TRANSISTOR
Q6250 2SC3928A/QR/-X TRANSISTOR
Q6251 2SC3928A/QR/-X TRANSISTOR
Q6301 2SA1530A/QR/-X TRANSISTOR
Q6302 HN1C01F/Y/-X PAIR TRANSISTOR
Q6303 2SA1530A/QR/-X TRANSISTOR
Q6304 HN1C01F/Y/-X PAIR TRANSISTOR
Q6501 2SC3928A/QR/-X TRANSISTOR
Q6502 2SC3928A/QR/-X TRANSISTOR
Q7032 UN2113-X TRANSISTOR
Q7033 UN2113-X TRANSISTOR
Q7034 UN2113-X TRANSISTOR
Q7035 UN2113-X TRANSISTOR
Q7201 2SC3928A/QR/-X TRANSISTOR
Q7301 2SC2412K/QR/-X TRANSISTOR
Q9501 UN2213-X DIGI TRANSISTOR
Q9502 2SC3928A/QR/-X TRANSISTOR
Q9503 2SC3928A/QR/-X TRANSISTOR
D6301 MA111-X SI DIODE
D6302 MA111-X SI DIODE
D6503 1SS355W-X DIODE
D7032 1SS355W-X DIODE
D7301 RB501V-40-X SB DIODE
D9001 EC30HA03L-X SB DIODE
 Ref No. Part No. Part Name Description Local
