JVC LT-26DR7BJ Service Manual

3-16(No.YA408)
LED P.W. BOARD ASS'Y (SFL-8904A-U2)
POWER P.W. BOARD ASS'Y (SFL-9046A-U2)
R7015 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R7016 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R7017 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7701 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R7702 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R7703 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R7704 NRSA63J-822X MG RESISTOR 8.2k Ω 1/16W J
R7707 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7708 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R7710 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R7711 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
L7001 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
L7002 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
J7001 QNS0051-001 3.5 JACK HEADPHONE
K7001 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
S7701 QSW0619-003Z PUSH SWITCH CH-
S7702 QSW0619-003Z PUSH SWITCH CH+
S7703 QSW0619-003Z PUSH SWITCH MENU/OK
S7704 QSW0619-003Z PUSH SWITCH TV/AV
S7705 QSW0619-003Z PUSH SWITCH VOL+
S7706 QSW0619-003Z PUSH SWITCH VOL-
S7707 QSW0619-003Z PUSH SWITCH POWER
 Ref No. Part No. Part Name Description Local
IC8952 GP1UM261RKVF IR DETECT UNIT
Q8901 RT1N241C-X DIGI TRANSISTOR
Q8904 RT1P440C-X DIGI TRANSISTOR
Q8905 RT1P440C-X DIGI TRANSISTOR
Q8909 RT1N241C-X DIGI TRANSISTOR
D8905 SML72420C-T LED POWER
C8952 NEHL1CM-476X E CAPACITOR 47uF 16V M
R8911 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R8913 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R8914 NRSA63J-331X MG RESISTOR 330 Ω 1/16W J
R8917 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R8926 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8927 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R8955 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
 Ref No. Part No. Part Name Description Local
IC9202 BA50BC0FP-X IC
IC9501 STR-X6768N-F2 IC
Q9001 2SC3928A/QR/-X TRANSISTOR
Q9503 2SC3928A/QR/-X TRANSISTOR
Q9505 2SC3928A/QR/-X TRANSISTOR
 D9001 TS25P05G-C2 BRIDGE DIODE
D9002 1SS355W-X DIODE
D9201 D2SBA60 BRIDGE DIODE
D9501 1SS355W-X DIODE
D9502 MTZJ33B-T2 Z DIODE
D9503 1SS355W-X DIODE
D9504 RF101L2S-X SI DIODE
D9505 RF101L2S-X SI DIODE
D9506 SARS01-T2 FR DIODE
D9507 SARS01-T2 FR DIODE
D9508 FR105GT-T3 SI DIODE
D9509 RL2Z-LFC4 SI DIODE
D9510 RL2Z-LFC4 SI DIODE
D9511 FMX-G22S SI DIODE
D9512 FMX-G22S SI DIODE
D9513 FMX-G22S SI DIODE
D9514 FR105GT-T3 SI DIODE
D9515 UTCTL431-T IC
D9516 MA3100/H/-X Z DIODE
D9517 MA3100/H/-X Z DIODE
D9518 1SS355W-X DIODE
D9519 UDZW3.0B-X Z DIODE
D9520 1SS355W-X DIODE
D9521 MA3100/H/-X Z DIODE
 Ref No. Part No. Part Name Description Local
 C9001 QFZ9072-105 MM CAPACITOR 1uF AC250V K
 C9002 QFZ9072-105 MM CAPACITOR 1uF AC250V K
 C9003 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9004 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9005 QCZ9078-222 C CAPACITOR 2200pF AC250V M
 C9007 QCZ9071-102 C CAPACITOR 1000pF AC400V M
 C9008 QCZ9071-102 C CAPACITOR 1000pF AC400V M
 C9012 QCZ9071-471 C CAPACITOR 470pF AC400V K
C9204 QEZ0814-475Z E CAPACITOR 4.7uF
C9206 QEHR1HM-105Z E CAPACITOR 1uF 50V M
 C9209 QCZ9071-471 C CAPACITOR 470pF AC400V K
C9211 QECR1CM-477Z E CAPACITOR 470uF 16V M
C9212 QEHR1AM-337Z E CAPACITOR 330uF 10V M
C9213 QEHR1CM-107Z E CAPACITOR 100uF 16V M
C9215 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9501 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9502 QEHR1HM-335Z E CAPACITOR 3.3uF 50V M
C9503 NCB31HK-102X C CAPACITOR 1000pF 50V K
C9504 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9505 NCB31HK-471X C CAPACITOR 470pF 50V K
C9506 QCZ0340-561 C CAPACITOR 560pF 2kV K
C9507 QEZ0739-337 E CAPACITOR 330uF
C9508 QFP32JK-332 PP CAPACITOR 3300pF 630V K
C9509 QEHR1HM-336Z E CAPACITOR 33uF 50V M
C9518 QECR2AM-156Z E CAPACITOR 15uF 100V M
C9519 QECQ1VM-128 E CAPACITOR 1200uF 35V M
C9520 QECQ1VM-128 E CAPACITOR 1200uF 35V M
C9521 QECQ1VM-128 E CAPACITOR 1200uF 35V M
C9522 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9523 QECQ1EM-188 E CAPACITOR 1800uF 25V M
C9525 QECR1EM-687Z E CAPACITOR 680uF 25V M
C9526 QECR1EM-687Z E CAPACITOR 680uF 25V M
C9527 QECR1EM-227Z E CAPACITOR 220uF 25V M
C9528 QECR1VM-227Z E CAPACITOR 220uF 35V M
C9529 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9530 NCB31HK-222X C CAPACITOR 2200pF 50V K
 R9001 QRZ9046-105Z C RESISTOR 1M Ω 1/2W K
R9003 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R9004 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
 R9209 QRZ9046-685Z C RESISTOR 6.8M Ω 1/2W K
R9501 NRS12BJ-224W MG RESISTOR 220k Ω 1/2W J
R9502 NRS12BJ-224W MG RESISTOR 220k Ω 1/2W J
R9503 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9504 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9505 QRK126J-101X UNF C RESISTOR 100 Ω 1/2W J
R9506 QRT029J-R27 MF RESISTOR 0.27 Ω 2W J
R9507 QRT029J-R27 MF RESISTOR 0.27 Ω 2W J
R9508 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R9509 QRL039J-220 OMF RESISTOR 22 Ω 3W J
R9510 QRE121J-564Y C RESISTOR 560k Ω 1/2W J
 R9512 QRE121J-470Y C RESISTOR 47 Ω 1/2W J
R9513 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9514 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9515 QRG01GJ-821 OMF RESISTOR 820 Ω 1W J
R9516 QRG01GJ-821 OMF RESISTOR 820 Ω 1W J
R9517 NRSA63J-123X MG RESISTOR 12k Ω 1/16W J
R9518 NRSA63D-273X MG RESISTOR 27k Ω 1/16W D
R9519 NRSA63J-152X MG RESISTOR 1.5k
Ω 1/16W J
R9520 NRSA63D-332X MG RESISTOR 3.3k Ω 1/16W D
R9521 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R9525 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R9526 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R9527 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R9528 QRL029J-182 OMF RESISTOR 1.8k
Ω 2W J
R9529 QRL029J-104 OMF RESISTOR 100k
Ω 2W J
R9531 NRS12BJ-102W MG RESISTOR 1k
Ω 1/2W J
R9532 NRSA63J-822X MG RESISTOR 8.2k
Ω 1/16W J
R9533 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R9534 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
 L9001 QQR1708-001 CHOKE COIL
L9201 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9502 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9503 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9504 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
 T9201 QAL0724-001 POWER TRANSF
 T9501 QQS0370-001 SW TRANSF
 CP9201 QMFZ052-2R0-E FUSE 2A AC250V
 CP9501 QMFZ049-5R0-E FUSE 5A 125V
 CP9502 QMFZ049-5R0-E FUSE 5A 125V
 CP9503 ICP-N70-T IC PROTECTOR 2.5A
 CP9504 ICP-N70-T IC PROTECTOR 2.5A
 CP9505 ICP-N70-T IC PROTECTOR 2.5A
 CP9506 QMFZ043-5R0Z-J1 FUSE 5A AC250V
 F9001 QMF5AD2-6R3-J1 FUSE 6.3A AC250V
K9202 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K9501 QRN143J-0R0X C RESISTOR 0 Ω 1/4W J
K9503 QRN143J-0R0X C RESISTOR 0
Ω 1/4W J
 Ref No. Part No. Part Name Description Local
