SPECIFICATION
Design & specifications are subject to change without notice.
Items Contents
Dimensions ( W × H × D ) 121.74 cm × 82.55 cm × 34.57 cm [With stand]
121.74 cm
× 77.85 cm × 13.5 cm [Without stand]
Mass 40.0 kg [With stand]
34.0 kg [Without stand]
Power Input AC110V - AC240 V, 50 Hz / 60 Hz
Power Consumption 277 W (Standby:0.5 W)
TV RF System B, G, I, D, K, K1, M
Colour System PAL / SECAM / NTSC 3.58 / NTSC 4.43
Stereo System A2 (B/G, D/K), NICAM (B/G, I, D/K)
Teletext System FLOF (Fastext), WST (World Standard System)
Receiving
Frequency
VHF Low
VHF High
UHF
CATV
46.25MHz - 140.25MHz
147.25MHz - 423.25MHz
431.25MHz - 863.25MHz
Mid (X - Z+2, S1 - S10) / Super (S11 - S20) / Hyper (S21 - S41) bands
Intermediate Frequency VIF
SIF
38.0MHz (B, G, I, D, K, L)
32.26MHz (5.74MHz: B), 32.15MHz (5.85MHz: G), 31.45MHz (6.55MHz: I)
31.75MHz (6.25MHz: D), 32.15MHz (5.85MHz: K)
Colour Sub
Carrier
PAL
SECAM
NTSC
4.43MHz
4.40625MHz / 4.25MHz
3.58MHz / 4.43MHz
LCD panel 52 V-inch wide aspect (16 : 9)
Screen Size Diagonal: 132.1 cm (H: 93.1 cm
× V: 52.4 cm)
Display Pixels Horizontal: 1920 dots × Vertical: 1080 dots
Audio Power Output 10 W + 10 W
Speaker 4.5 cm × 16.0 cm, Twin Oblique cone × 2
Aerial terminal (VHF/UHF) 75 Ω unbalanced, coaxial
Video / Audio
Input-1/2/3
Component Video
[Input-1/3]
750p / 1125i
625p / 525p / 625i / 525i
RCA pin jack × 6 (Input-3)
Y: 1V (p-p) (Sync signal: ±0.35V(p-p), 3-value sync.), 75 Ω / Pb/Pr: ±0.35V(p-p),
75 Ω
Y: 1V (p-p), Positive (Negative sync provided), 75 Ω / Pb/Pr: 0.7V(p-p), 75 Ω
S-Video
[Input-1/2]
Mini-DIN 4 pin connector × 2
Y: 1 V (p-p), Positive (Negative sync provided), 75 Ω
C: 0.286 V (p-p) (Burst signal), 75 Ω
Video 1 V (p-p), Positive (Negative sync provided), 75 Ω, RCA pin jack × 3
Audio 500 mV (rms), High impedance, RCA pin jack × 6
Video / Audio Output S-Video Mini-DIN 4 pin connector × 1
Y: 1 V (p-p), Positive (Negative sync provided), 75 Ω
C: 0.286 V (p-p) (Burst signal), 75 Ω
Video 1 V (p-p), Positive (Negative sync provided), 75 Ω, RCA pin jack × 1
Audio 500 mV (rms), Low impedance, RCA pin jack × 2
HDMI Input Video HDMI connector × 3
(Digital-input terminal is not compatible with picture signals of computer signal)
Audio Analog: 500mV(rms) (-4dBs), high impedance, RCA pin jack × 2
PC (RGB) Input D-sub 15 pin × 1
R/G/B: 0.7 V (p-p), 75Ω
HD / VD: 1 V (p-p) to 5 V (p-p), high impedance
< Available signal >
VGA: 640 pixels × 480 pixels (Horizontal: 31.5 kHz / Vertical: 60 Hz)
XGA: 1024 pixels × 768 pixels (Horizontal: 48.4 kHz / Vertical: 60 Hz)
Headphone 3.5 mm stereo mini jack × 1
Remote Control Unit RM-C1856 (AAA/R03 dry cell battery × 2)

JVC LT-52GZ79 Specifications

General

Brand	JVC
Model	LT-52GZ79
Category	TV
Language	English
