3-22(No.YA665<Rev.001>)
PRINTED WIRING BOARD PARTS LIST [LT-52GZ79/S]
ANALOG P.W. BOARD ASS'Y (SFL-1237A-H2)
REFER TO PARTS LIST IN PAGE 3-7 FOR THIS P.W. BOARD.
SW P.W. BOARD ASS'Y (SFL-7221A-H2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
LED P.W. BOARD ASS'Y (SFL-8728A-H2)
REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.
POWER P.W. BOARD ASS'Y (SFL-90A6A-H2)
REFER TO PARTS LIST IN PAGE 3-11 FOR THIS P.W. BOARD.
DC-DC P.W. BOARD ASS'Y (SFL-91A1A-H2)
REFER TO PARTS LIST IN PAGE 3-13 FOR THIS P.W. BOARD.
DIGITAL P.W. BOARD ASS'Y (SFL0D404A-H2)
 Ref No. Part No. Part Name Description Local
IC5001 JCC5070 IC
IC5002 EDD1232ABBH-5C IC
IC5003 EDD1232ABBH-5C IC
IC5503 BU7986KUT IC
IC6001 JCC5068 IC
IC6002 74LVC1G08GW-X IC
IC6004 ICS574MLF-X IC
IC6101 EDD1232AAFA-6B IC
IC6102 AIC1384PSH-X IC
IC6250 UPC5702GS-027-X IC
IC6251 S-1170B33UC-W IC
IC6301 TC7SET08F-X IC
IC6302 TC7SET08F-X IC
IC6303 TC7SH86FU-X IC
IC6503 BU7986KUT IC
IC6509 TC7SET08F-X IC
IC6510 MM3143DN-X IC
IC6724 S-80928CLNB-G-W IC
IC6901 R1141Q331B-X IC
IC7033 74HC4094PW-X IC
IC7036 ADC081S021CIS-X IC
IC7201 39VF80A7IEKLJ09 IC(MICRO C ROM)
IC7203 M12L16161A7T11U IC
IC7204 S-80928CLNB-G-W IC
IC7301 SDA6000-B12 IC
IC7302 SA16D90-52GZ IC(MICRO C ROM) (SERVICE)
IC7303 K4S641632K-UC75 IC
IC7304 TC74HC4053AFT-X IC(DIGITAL)
IC7305 MM1689CH-X IC
IC7306 S-80928CLNB-G-W IC
IC7602 ATF32-52GZ79S IC (SERVICE)
IC7606 MM1671XN-X IC
IC9000 THV1021-X IC
IC9101 MM1662FT-X IC
IC9102 MM1662FT-X IC
IC9251 MM1701CH-X IC
IC9301 MM1701CH-X IC
Q6202 2SA1530A/QR/-X TRANSISTOR
Q6203 RT1A3906-X TRANSISTOR
Q6204 RT1A3906-X TRANSISTOR
Q6205 RT1A3906-X TRANSISTOR
Q6206 RT1A3906-X TRANSISTOR
Q6207 2SC5477-X TRANSISTOR
Q6208 2SC5477-X TRANSISTOR
Q6209 2SC5477-X TRANSISTOR
Q6210 2SC5477-X TRANSISTOR
Q6211 2SC5477-X TRANSISTOR
Q6212 2SC5477-X TRANSISTOR
Q6213 2SC5477-X TRANSISTOR
Q6214 2SC5477-X TRANSISTOR
Q6250 2SC3928A/QR/-X TRANSISTOR
Q6251 2SC3928A/QR/-X TRANSISTOR
Q6301 2SA1530A/QR/-X TRANSISTOR
Q6302 HN1C01F/Y/-X PAIR TRANSISTOR
Q6303 2SA1530A/QR/-X TRANSISTOR
Q6304 HN1C01F/Y/-X PAIR TRANSISTOR
Q6501 2SC3928A/QR/-X TRANSISTOR
Q6505 INK0001AM1-X MOS FET
Q6506 INK0001AM1-X MOS FET
Q7030 RT1N441C-X TRANSISTOR
Q7032 RT1P441C-X DIGI TRANSISTOR
Q7033 RT1P441C-X DIGI TRANSISTOR
Q7034 RT1P441C-X DIGI TRANSISTOR
Q7035 RT1P441C-X DIGI TRANSISTOR
Q7041 RT1N441C-X TRANSISTOR
Q7301 UN2213-X DIGI TRANSISTOR
Q9010 UN2212-X DIGI TRANSISTOR
Q9051 RSS040P03-X POWER MOS FET
Q9052 UN2212-X DIGI TRANSISTOR
Q9701 RSS040P03-X POWER MOS FET
D6301 MA111-X SI DIODE
D6302 MA111-X SI DIODE
D6502 MA111-X SI DIODE
D6504 MA111-X SI DIODE
D7301 RB501V-40-X SB DIODE
D7302 1SS357-X DIODE
D7303 RB521S-30-X SB DIODE
D9051 EC30HA03L-X SB DIODE
D9053 PTZ3.9B-X Z DIODE
D9701 EC30HA03L-X SB DIODE
D9703 PTZ3.9B-X Z DIODE
C5001 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5002 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5003 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5004 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5005 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5006 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5007 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5008 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5009 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5010 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5011 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5012 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5013 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5014 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5015 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5016 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5017 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5018 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5019 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5020 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5021 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5022 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5023 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5024 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5025 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5026 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5027 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5028 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5029 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5030 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5031 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5032 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5033 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5034 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5035 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5036 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5037 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5038 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5039 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5040 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5041 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5042 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5043 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5044 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5045 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5046 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5047 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5048 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5051 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5052 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5053 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5054 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5055 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5056 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5057 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C5058 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Ref No. Part No. Part Name Description Local
